Voltcraft MMS-130 Safety Test Lead Set with Clamps, 4 mm Banana Plug, 1.2 m, CAT III 1000 V, Black/Red VC-17155590

Rated for CAT III 1000 V and CAT IV 600 V, the Voltcraft MMS-130 test lead set delivers safe, reliable measurements in demanding electrical environments. Each lead combines a nickel-plated brass safety test clamp with a straight 4 mm safety banana plug, connected by a highly flexible 0.75 mm² PVC-insulated cable. The set includes one black and one red lead, each 1.2 m long, for clear polarity identification and comfortable reach. With a nominal current of 10 A and an operating temperature range from -15 to +70 °C, these leads are built for professional use in laboratories, industrial maintenance, and field service.

Overview

The MMS-130 is a complete test lead set designed for secure, hands-free measurements. The safety test clamps feature strong spring action and serrated jaws to grip terminals, wires, and component leads firmly. The 4 mm banana plugs are shrouded for safety and fit standard multimeter inputs. The PVC insulation provides excellent flexibility and abrasion resistance, while the nickel-plated brass contacts ensure low contact resistance and long-term reliability. The leads are colour-coded black and red for easy identification of common and live connections.

What stands out

• High safety rating: CAT III 1000 V and CAT IV 600 V for use on building wiring and primary supply circuits.
• Versatile connections: safety test clamp on one end, straight 4 mm safety banana plug on the other.
• Flexible and durable: 0.75 mm² PVC-insulated cable with a length of 1.2 m per lead.
• Reliable contacts: nickel-plated brass clamp and plug ensure stable, low-resistance measurements.
• Clear identification: one black and one red lead for correct polarity and easy tracing.
• Wide temperature range: operates from -15 to +70 °C for use in various environments.

Technical details

• Connection type A: Safety test clamp
• Connection type B: 4 mm safety banana plug, straight
• Cable length: 1.20 m per lead
• Nominal voltage: 1000 V
• Nominal current: 10 A
• Safety category: CAT III 1000 V, CAT IV 600 V
• Insulation material: PVC
• Cable colour: Black, red
• Contact material: Nickel-plated brass
• Cable cross-section: 0.75 mm²
• Operating temperature range: -15 to +70 °C
• Set contents: 2x test leads (red/black), 2x safety test clamps (red/black)

Our verdict

The Voltcraft MMS-130 test lead set offers professional-grade safety and performance at a practical price. Its robust clamps and high voltage rating make it a dependable choice for electricians and technicians who need secure, hands-free measurements in a variety of settings.
