VOLTCRAFT MSL-503-2 Test Lead Set, 4 mm Safety Plug to 4 mm Safety Plug, 39 cm, 10 A, 1000 V, CAT III/IV, Black/Red, 2 Leads VC-18654460

Precision measurements demand reliable connections. The VOLTCRAFT MSL-503-2 test lead set eliminates contact uncertainty with spring-loaded lamella plugs that grip firmly in 4 mm safety sockets, ensuring stable readings even in high-vibration environments. Each set includes one black and one red lead, colour-coded for instant polarity identification.

Who is it for

Professional electricians, electronics engineers, and laboratory technicians who require safe, repeatable measurements on CAT III and CAT IV installations. Ideal for multimeter users needing short, low-resistance leads for bench work or field diagnostics.

Main features

• 39 cm lead length reduces clutter and minimises resistance for accurate low-voltage measurements.
• 4 mm safety plugs on both ends with lamella contacts ensure secure, low-contact-resistance connections.
• Rated for 10 A continuous current and 1000 V, with CAT III 1000 V / CAT IV 600 V safety classification.
• Flexible PVC insulation and 1 mm² copper conductors balance durability and handling.
• Complies with IEC/EN 61010-031, providing verified protection against electrical hazards.

Specifications

• Connector type: 4 mm safety plug to 4 mm safety plug
• Number of leads: 2 (1 black, 1 red)
• Cable length: 39 cm
• Current rating: 10 A
• Voltage rating: 1000 V
• Safety category: CAT III 1000 V / CAT IV 600 V
• Conductor cross-section: 1 mm²
• Contact resistance: < 30 mΩ
• Insulation material: PVC
• Plug housing material: Polyamide (PA)
• Operating temperature range: -10 °C to +70 °C
• Safety standard: IEC/EN 61010-031

Tips

Store leads loosely coiled to prevent insulation kinking. For high-energy circuits, always verify the multimeter's CAT rating matches the leads. Replace immediately if the plug insulation shows cracks or the lamella loses spring tension.
