TRYTYT PG13.5 Cable Gland Light Grey PA6 IP68 for 6-12mm Cables (1 pc)

Unsealed cable entry points in electrical enclosures, junction boxes, and control panels invite dust, moisture, and mechanical stress, leading to premature equipment failure and safety hazards. This PG13.5 cable gland from TRYTYT provides a robust, IP68-rated sealing solution for cables with diameters from 6 to 12 mm, ensuring long-term reliability in industrial environments.

Who is it for

Electrical engineers, panel builders, and maintenance technicians working with industrial machinery, automation systems, or outdoor installations will appreciate the gland's durable construction and ease of installation. It is suitable for both new builds and retrofits where a secure, strain-relieved cable entry is required.

Main features

• PG13.5 thread size with 10 mm thread length for standard mounting holes of 20.5 mm diameter.
• Made of polyamide PA6 in light grey (RAL 7035), offering excellent mechanical strength and UV resistance for outdoor use.
• IP68 protection rating ensures complete dust tightness and resistance to continuous immersion in water, safeguarding internal components.
• NBR gasket provides a reliable seal around cables from 6 to 12 mm in diameter, accommodating a wide range of common cable sizes.
• Integrated strain relief prevents cable pull-out and reduces stress on internal connections, enhancing overall system durability.
• Flame retardant to UL94-V2 and halogen-free, contributing to safer installations in case of fire.
• Complies with EN 50262 and RoHS, meeting stringent European standards.

Specifications

• Thread type: PG
• Thread size: PG13.5
• Thread length: 10 mm
• Mounting hole diameter: 20.5 mm
• Wrench size (nut): 24 mm
• Material: Polyamide PA6
• Colour: Light grey (RAL 7035)
• Gasket material: NBR
• Cable diameter range: 6–12 mm
• IP rating: IP68
• Operating temperature: -20°C to +80°C
• Flame retardancy: UL94-V2
• Halogen-free: Yes
• UV resistant: Yes
• Standards: EN 50262, RoHS
• Quantity per pack: 1 piece
• Manufacturer series: KPG

Tips

For optimal sealing, ensure the cable outer diameter falls within the 6–12 mm range and the mounting hole is exactly 20.5 mm. Hand-tighten the gland firmly, then add a quarter turn with a wrench—do not overtighten, as this may damage the gasket. In outdoor applications, position the gland to avoid direct water jets and consider using a sealing washer for additional protection.
