TRYTYT PG-16 Light Grey Cable Gland with Strain Relief IP68 (1 pc)

Industrial cable gland with PG-16 thread, providing secure strain relief and IP68 protection for cables with diameters from 9 to 14 mm. Its light grey polyamide 6 housing with NBR seal ensures reliable sealing in demanding environments, from -40°C to +100°C.

Advantages

The PG-16 cable gland offers robust strain relief and excellent environmental sealing. The polyamide 6 construction is halogen-free and flame-retardant (UL94-V2), while the NBR seal maintains flexibility across a wide temperature range. The light grey colour (RAL 7035) blends seamlessly into industrial control panels and junction boxes.

Suitable for

• Industrial electrical installations
• Junction boxes and control cabinets
• Automation and machinery wiring
• Outdoor and harsh environment applications

Key specifications

• Thread type: PG (Panzergewinde)
• Thread size: PG-16
• Cable diameter range: 9 - 14 mm
• IP rating: IP68
• Material: Polyamide 6 (PA6)
• Colour: Light grey (RAL 7035)
• Seal material: NBR (Nitrile Butadiene Rubber)
• Operating temperature: -40°C to +100°C
• Short-term temperature resistance: up to +120°C
• Flammability rating: UL94-V2
• Halogen-free: Yes
• Wrench size: 27 mm
• Thread length: 10 mm
• Mounting hole diameter: 22.5 mm
• Certifications: CE, RoHS

Recommendations

For optimal sealing, ensure the cable diameter falls within the specified range and tighten the gland to the recommended torque. Use a 27 mm wrench for installation. Suitable for use with standard PG-16 knockouts or threaded entries.
