Tilt Integrated Headset Blue

The Tilt Integrated Headset in Blue is a high-performance headset designed for pro scooters and BMX bikes. Featuring sealed cartridge bearings and a press-fit design, it offers a clean, integrated look with reliable performance and corrosion resistance.

Advantages

Sealed cartridge bearings provide smooth rotation and long-lasting durability, while the integrated design eliminates the need for external cups, simplifying installation and reducing weight. The 6061 T-6 aluminum top cap adds strength without adding bulk.

Suitable for

• Pro Scooters
• BMX Bikes
• Riders seeking a low-maintenance, high-performance headset

Key specifications

• Headset Type: Integrated
• Bearing Type: Sealed Cartridge Bearings
• Steerer Tube Diameter: 1 1/8" (28.6mm) Threadless
• Head Tube Standard: IS42/28.6 | IS42/30
• Bearing Outer Diameter: 41.8 mm
• Bearing Angle: 45° x 45°
• Top Cap Material: 6061 T-6 Aluminum
• Bearing Material: Chrome Steel
• Color: Blue
• Includes: 2x Bearings, 1x Top Cap, 1x Compression Ring, 1x Crown Race
• Stack Height: 8 mm
• Dust Cover: Yes, integrated with top cap
• Installation: Press-fit bearings (no external cups required)
• Corrosion Resistance: Yes (sealed bearings)

Recommendations

For optimal performance, ensure your frame's head tube is compatible with IS42/28.6 or IS42/30 standards. Professional installation is recommended for press-fit bearings.
