Omni-directional antenna Teltonika PR1IC970 0.617-4.3 GHz Wi-Fi

The Teltonika PR1IC970 is an omni-directional outdoor antenna that covers a wide frequency range of 0.617–4.3 GHz and provides a maximum gain of 28 dBi. Designed for use with routers such as the RUTX11 and RUTM11, it features a 50 Ω impedance and an SMA male connector. With compact dimensions (160 × 189 × 347 mm), 1.5 kg weight and RoHS compliance, the antenna is intended to improve wireless reception for LTE, Wi‑Fi, GPS and Bluetooth in diverse outdoor installations.

Advantages

The antenna offers broad frequency support from 0.617 to 4.3 GHz, high maximum gain of 28 dBi and a standard 50 Ω interface for compatibility with common router ports. Its SMA male connector ensures easy connection to supported devices, while the compact housing and moderate weight simplify mounting and integration into outdoor setups. RoHS compliance indicates adherence to environmental safety standards.

Suitable for (tasks / use cases)

• Enhancing LTE signal reception for remote or outdoor routers
• Improving Wi‑Fi coverage in outdoor areas
• Supporting GPS and Bluetooth connectivity in mixed wireless deployments
• Use with Teltonika RUTX11 and RUTM11 routers and other devices with SMA male/female compatibility

Key specifications

• Frequency range: 0.617–4.3 GHz
• Maximum gain: 28 dBi
• Impedance: 50 Ω
• Connector: SMA male
• Input voltage: 2.5–6.5 V
• Dimensions (W × D × H): 160 × 189 × 347 mm
• Weight: 1.5 kg
• Compliance: RoHS

How to use

Mount the PR1IC970 outdoors following local mounting and grounding regulations. Connect the SMA male connector to the router antenna port (or via an appropriate adapter or coaxial cable if needed). Position the antenna for optimal omnidirectional coverage, clear of large metal obstructions. After physical installation, verify signal levels in the router interface and adjust placement if necessary to achieve the desired reception improvement.

Recommendations

Use appropriate weatherproofing for any cable connections and ensure proper grounding to protect the antenna and connected equipment. For best results with LTE and Wi‑Fi, place the antenna at a height and location with minimal obstructions and check compatibility with the router’s antenna ports before installation.
