SHIVERPEAKS BS15-15002 TV Signal Amplifier 47-782 MHz, 20 dB Gain, F-Connectors, 230V

Where most indoor TV amplifiers compromise on shielding or introduce noticeable noise, the SHIVERPEAKS BS15-15002 stands out with a robust metal housing and a low noise figure under 6 dB. It is built to cleanly boost weak terrestrial and cable signals across the full 47–782 MHz band, making it a dependable fix for pixelation, dropouts, or long coaxial runs.

Highlights

• Wide frequency coverage: 47–782 MHz supports DVB-T, DVB-C, analog TV, and FM radio.
• 20 dB gain lifts marginal signals without excessive overdrive.
• Low noise figure (< 6 dB) preserves signal quality.
• 75-ohm F-type input and output for standard coaxial connections.
• Metal housing shields against interference and aids heat dissipation.
• Compact, mains-powered design (230V AC) for indoor installation.

In daily use

Connect the amplifier between your antenna wall outlet and TV or set-top box. The F-type connectors ensure a secure, low-loss link. With a maximum output level of 100 dBµV (DIN 45004B) and return loss better than 10 dB, it handles multiple channels without visible degradation. The 3 W power consumption is negligible, and the operating range of -20°C to +50°C allows placement in attics or utility rooms.

Full specifications

• Frequency range: 47–782 MHz
• Gain: 20 dB
• Noise figure: < 6 dB
• Max. output level: 100 dBµV (DIN 45004B)
• Input/output impedance: 75 Ohm
• Connectors: F-type female (input and output)
• Return loss: > 10 dB
• Power supply: 230V AC, 50 Hz
• Power consumption: 3 W
• Housing material: metal
• Operating temperature: -20°C to +50°C
• Supported standards: DVB-T, DVB-C, analog TV, FM radio
• Number of outputs: 1

Final note

For a straightforward, well-shielded signal boost across the entire TV and radio spectrum, the SHIVERPEAKS BS15-15002 delivers reliable performance without unnecessary complexity.
