HDMI to VGA Converter Vention 0.15M Black HDMI Type A VGA D-Sub Micro USB Audio

The Vention HDMI to VGA Converter (0.15 m) provides a simple way to connect HDMI source devices to VGA displays. The compact black adapter integrates an HDMI Type A male connector, VGA (D-Sub) female output, a 3.5 mm audio jack and a Micro-USB Type B power input to enable video and audio conversion for legacy monitors and projectors.

Advantages

This adapter supports 1920 x 1080 pixels at 60 Hz for clear Full HD output from HDMI sources to VGA displays. The short 0.15 m cable reduces clutter near the connected device and the integrated 3.5 mm audio jack allows separate audio output when the VGA display lacks sound. Micro-USB power input ensures stable signal conversion when additional power is required.

Suitable for

• Connecting laptops or media players with HDMI output to VGA monitors or projectors
• Presentations in meeting rooms and classrooms
• Using older displays without HDMI input while preserving audio via the 3.5 mm jack

Key specifications

• Cable length: 0.15 m
• Input connector: HDMI Type A (Standard) straight male
• Output connectors: VGA (D-Sub) straight female, 3.5 mm audio jack, Micro-USB Type B (power)
• Maximum supported resolution: 1920 x 1080 pixels at 60 Hz
• Brand: Vention
• MPN: 42161.00
• EAN: 6922794742161

How to use

Plug the HDMI Type A male connector into the HDMI output of your source device. Connect the VGA cable from your monitor or projector to the VGA D-Sub female port on the adapter. If audio is required, connect a 3.5 mm audio cable from the adapter to external speakers or the display's audio input. If the source device cannot supply sufficient power to the converter, connect a Micro-USB cable to the Micro-USB Type B port and a suitable USB power source.

Recommendations

For reliable operation, use the adapter with devices that output common HDMI formats up to 1080p60 and provide optional power via Micro-USB when needed. Avoid sharp bends in the short cable and connect or disconnect connectors with the devices powered off when possible to prevent signal issues.
