Satellite multiswitch Televes 714201 9 inputs 17 outputs

The Televes 714201 satellite multiswitch supplies signal distribution from two satellites and a terrestrial antenna to multiple receivers. It features nine inputs (one terrestrial and eight satellite polarities) and seventeen outputs, supporting input frequencies from 950 to 2400 MHz. The unit can be installed as a terminal in a star topology or used in cascade with a simple switch, and it is designed and manufactured in Europe.

Advantages

This multiswitch is quad-compatible and includes a 22 kHz generator for optimized operation with Quad LNBs. Each group of eight user outputs has a 10 dB Low Gain/High Gain switch for attenuating satellite input signals as needed. The device is compatible with return-channel applications and offers compact dimensions (208 × 30 × 120 mm) with low current consumption (125 mA) at 12 V operation.

Suitable for

• Distributing satellite and terrestrial TV signals to multiple receivers in homes or small buildings
• Installations using Quad LNBs and multi-satellite configurations
• Setups requiring cascade connection or star-topology terminal distribution

Key specifications

• Model: Televes 714201
• Inputs: 9 (1 terrestrial + 8 satellite polarities)
• Outputs: 17
• Frequency range: 950–2400 MHz
• Supply voltage: 12 V
• Signal level range: 90–112 dBμV
• Current consumption: 125 mA
• Dimensions (W×D×H): 208 × 30 × 120 mm
• EAN: 8424450187418

How to use

Connect the terrestrial antenna to the terrestrial input and the two satellite LNBs to the satellite inputs (all four polarities per satellite). Mount the multiswitch in a suitable cabinet or on a wall, provide a 12 V power supply, and route coaxial cables from the user outputs to each receiver. Use the 10 dB LG/HG switch for each eight-user group to adjust satellite signal attenuation when necessary. For cascade installations, use a compatible switch to link units as required.

Recommendations

For stable reception, verify cable quality and connector integrity, set the LG/HG switches according to signal levels measured at receivers, and ensure the Quad LNB is compatible with the 22 kHz generator. Follow local grounding and installation standards during setup.
