ROLINE Fiber Optic Patch Cable OS2 2m E-2000 LSH/APC Simplex LSZH Yellow

The ROLINE Fiber Optic Patch Cable is a high-performance single-mode patch cord designed for reliable data transmission in fiber optic networks. With a length of 2 meters and E-2000 LSH/APC connectors on both ends, this cable ensures low insertion loss and high return loss, making it ideal for critical applications.

Advantages

This patch cable offers excellent signal integrity with typical insertion loss ≤0.2 dB and return loss ≥60 dB. The APC polish minimizes back reflection, ensuring stable connections. The LSZH jacket provides safety in enclosed spaces by emitting low smoke and no halogen in case of fire.

Suitable for

• Fiber optic network installations in data centers, telecom rooms, and enterprise networks
• Single-mode OS2 applications requiring high bandwidth and long-distance transmission
• Environments where fire safety is a priority due to LSZH jacket

Key specifications

• Cable Type: Fiber Optic Patch Cord
• Fiber Mode: Single-mode OS2 (ITU-T G.657.A1/G.652.D)
• Connector Type: E-2000 LSH/APC (both ends)
• Connector Polishing: APC (Angled Physical Contact)
• Number of Fibers: 1 (Simplex)
• Core/Cladding Diameter: 9/125 µm
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Color: Yellow
• Cable Diameter: 2.0 mm
• Minimum Bend Radius: 10 mm
• Operating Wavelengths: 1310 nm, 1550 nm
• Compliance: RoHS, REACH

Recommendations

For optimal performance, ensure connectors are clean before mating. This cable is compatible with standard E-2000 LSH/APC adapters and equipment.
