ROGER MCT68ME-IO-I Proximity Reader, Black, RS485/Wiegand/OSDP, 125kHz/13.56MHz, IP65

The ROGER MCT68ME-IO-I is a versatile proximity reader designed for modern access control systems. It supports multiple card technologies including EM 125 kHz, MIFARE Classic, MIFARE DESFire EV1/EV2/EV3, MIFARE Plus, FeliCa, and NFC, making it compatible with a wide range of credentials. The reader communicates via RS485 (RACS protocol), Wiegand (26-66 bit), or OSDP v2.1.7, ensuring seamless integration into existing infrastructures.

Advantages

With a reading range of up to 8 cm and a robust IP65 rating, the MCT68ME-IO-I performs reliably in harsh environments. Its multi-color LED and built-in buzzer provide clear visual and audio feedback. The device includes two configurable digital inputs and one transistor output, enabling direct control of auxiliary devices. Optical tamper detection enhances security.

Suitable for

• Access control systems in commercial buildings, offices, and industrial facilities
• Integration with RACS 5 access control systems
• Indoor and outdoor installations requiring weather resistance

Key specifications

• Supported Card Technologies: EM 125 kHz, MIFARE Classic, MIFARE DESFire EV1/EV2/EV3, MIFARE Plus, FeliCa, NFC
• Operating Frequencies: 125 kHz, 13.56 MHz
• Communication Interface: RS485 (RACS protocol), Wiegand (26-66 bit), OSDP v2.1.7
• Reading Range: Up to 8 cm
• Power Supply: 10-15V DC
• Current Consumption: Max. 120 mA
• Ingress Protection: IP65
• Operating Temperature: -25°C to +60°C
• Housing Material: ABS Plastic
• Mounting Type: Surface Mount
• Visual Indicators: Multi-color LED (Red, Green, Blue)
• Audio Indicator: Built-in Buzzer
• Tamper Detection: Yes (optical)
• Digital Inputs: 2 (NO/NC configurable)
• Digital Outputs: 1 (transistor, 150mA/30V)
• Firmware Update: Yes, via RS485
• Color: Black
• Compatibility: RACS 5 Access Control System
• Certifications: CE
• Encryption: AES 128-bit (for OSDP communication)

Recommendations

For optimal performance, use with ROGER controllers and ensure proper power supply within 10-15V DC. The reader supports OSDP for secure encrypted communication. Regular firmware updates via RS485 are recommended to maintain compatibility and security.
