Power inverter MEAN WELL CSP-3000-120, 3000 W, input 180–264 V, output 120 V, 177.8×278×63.5 mm

MEAN WELL CSP-3000-120 is a 3000 W inverter/adapter designed to provide a stable 120 V AC output from a wide AC input range of 180–264 V. Housed in a compact metal enclosure with dimensions 177.8×278×63.5 mm, the unit integrates PFC and an AC-DC single output topology delivering 120 Vdc at 25 A with remote ON/OFF control. The product meets RoHS requirements and is intended for applications that require continuous high-power AC or DC supply with a compact footprint.

Advantages

The CSP-3000-120 offers a high continuous power rating of 3000 W in a compact metal housing, allowing installation in constrained spaces. Built-in power factor correction improves input efficiency and reduces reactive current. Remote ON/OFF control enables integration with external control systems or automated power management. Compliance with RoHS ensures the design follows environmental and material safety guidelines.

Suitable for

• Powering 120 V AC equipment in locations with 180–264 V AC supply
• Backup power systems and UPS applications requiring a stable 3000 W output
• Industrial devices and machinery that need a reliable 120 V DC/AC source at 25 A
• Integration into control cabinets or OEM systems where remote ON/OFF is needed

Key specifications

• Continuous output power: 3000 W
• Input voltage range: 180–264 V AC
• Output voltage: fixed 120 V
• DC output current capability: 25 A at 120 Vdc
• Enclosure material: metal
• Dimensions: 177.8 × 278 × 63.5 mm
• Built-in Power Factor Correction (PFC)
• Remote ON/OFF control function
• RoHS compliant

How to use

Install the inverter on a flat surface or inside a ventilation-enabled cabinet, ensuring adequate airflow around the metal housing. Connect the AC input to a 180–264 V supply following local electrical codes and ensure proper grounding. Connect the 120 V output to the load, observing the maximum continuous current rating of 25 A. Use the remote ON/OFF terminals to integrate with external control circuits or automation systems. Verify polarity and connections before powering on and monitor the device during initial startup for correct operation.

Recommendations

For reliable operation, allow at least 20 mm clearance around the unit for ventilation, avoid mounting near heat sources, and use appropriately rated wiring and protective devices sized for 3000 W continuous load. Periodically inspect terminals and cooling paths for dust build-up and ensure the remote control wiring is free from electrical noise to prevent unintended switching.
