Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX

Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
36 mo.
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
Motherboard GIGABYTE B650E AORUS STEALTH ICE, AMD B650E, Socket AM5, ATX
R7,666
The GIGABYTE B650E AORUS STEALTH ICE is an ATX motherboard for Socket AM5 supporting AMD Ryzen 7000, 8000 and 9000 series CPUs. It delivers a robust 12+2+2 VRM phase power design, up to 256 GB of DDR5 memory (up to 8000 MHz), one PCIe 5.0 slot and two PCIe 4.0 M.2 slots, 2.5GbE LAN and Wi‑Fi 7 conne... Read More
Stock Out Of StockNo Stock Code 2577954 Brand GIGABYTE Model B650EASTEALTHICE Warranty 3 Years

Shipping & Returns

The GIGABYTE B650E AORUS STEALTH ICE is an ATX motherboard for Socket AM5 supporting AMD Ryzen 7000, 8000 and 9000 series CPUs. It delivers a robust 12+2+2 VRM phase power design, up to 256 GB of DDR5 memory (up to 8000 MHz), one PCIe 5.0 slot and two PCIe 4.0 M.2 slots, 2.5GbE LAN and Wi‑Fi 7 connectivity, and compatibility with both HDD and SSD storage drives for high-performance desktop systems.

Advantages

The board combines a strong VRM design for stable CPU power delivery with high-frequency DDR5 support and next-generation PCIe connectivity, enabling demanding workloads and gaming. Integrated 2.5GbE LAN and Wi‑Fi 7 provide fast networking options, while multiple M.2 slots and large memory capacity support advanced storage and multitasking setups.

Suitable for

  • Gaming rigs requiring PCIe 5.0 and high memory bandwidth
  • Content creation and video editing workstations
  • High-performance home or small office PCs

Key specifications

  • Form factor: ATX
  • Chipset: AMD B650
  • Socket: Socket AM5 (supports AMD Ryzen 7000/8000/9000)
  • VRM phases: 12+2+2
  • Memory: 4 slots, DDR5 up to 8000 MHz, maximum 256 GB
  • Expansion/storage: 1 × PCIe 5.0 slot, 2 × PCIe 4.0 M.2 slots
  • Network: 2.5GbE LAN, Wi‑Fi 7
  • Storage support: HDD and SSD drives

How to use

Install the motherboard into a compatible ATX case and mount a Socket AM5 CPU following the CPU and cooler manufacturer instructions. Populate DDR5 modules across the four memory slots according to the motherboard manual to enable dual- or quad-channel operation. Connect NVMe SSDs to the M.2 slots and attach SATA drives if required. Configure BIOS/UEFI settings for memory frequency, boot order and storage modes, and install the operating system and chipset drivers from GIGABYTE for optimal performance.

Recommendations

For stable high-frequency DDR5 operation and heavy CPU loads, use quality cooling for the CPU and case airflow, install matched memory kits, and keep the BIOS updated to the latest GIGABYTE release.
Key Highlights
  • Gaming rigs requiring PCIe 5.0 and high memory bandwidth
  • Content creation and video editing workstations
  • High-performance home or small office PCs
  • Form factor: ATX
  • Chipset: AMD B650
  • Socket: Socket AM5 (supports AMD Ryzen 7000/8000/9000)
  • VRM phases: 12+2+2
  • Memory: 4 slots, DDR5 up to 8000 MHz, maximum 256 GB
  • Expansion/storage: 1 × PCIe 5.0 slot, 2 × PCIe 4.0 M.2 slots
  • Network: 2.5GbE LAN, Wi‑Fi 7
  • Storage support: HDD and SSD drives
Specifications
12V power connector
Yes
1st M.2 highest PCI Express generation
5.0
1st M.2 largest key size
25110
2nd M.2 highest PCI Express generation
4.0
2nd M.2 largest key size
22110
3rd M.2 highest PCI Express generation
4.0
3rd M.2 largest key size
22110
ACPI version
5.0
Antenna included
Yes
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC897
Audio output channels
7.1
Batteries included
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Battery weight
3 g
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.4
Bundled software
Norton Internet Security (OEM version) LAN bandwidth management software
Clear CMOS jumper
Yes
Component for
PC
Country of origin
China
CPU fan connector
Yes
Depth
244 mm
Desktop Management Interface (DMI) version
2.7
DirectX version
12.0
Discrete graphics support
Yes
DisplayPort version
1.4
Drivers included
Yes
DVI-D ports quantity
0
ECC сompatibility
non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
HDCP
Yes
HDMI ports quantity
1
HDMI version
2.1
Headphone outputs
1
Height
35 mm
LAN controller
Realtek RTL8125
Line-in
Yes
Lithium weight per battery
0.07 g
Maximum internal memory
256 GB
Maximum internal memory per slot
64 GB
Maximum resolution
4096 x 2160
Memory channels
Dual-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
AMD B650
Motherboard chipset family
AMD
Motherboard form factor
ATX
Number of battery cells
1
Number of chassis fan connectors
4
Number of CPU fan connectors
2
Number of EPS power connectors (8-pin)
1
Number of HDDs supported
4
Number of M.2 (M) slots
3
Number of memory slots
4
Number of RGB LED pin headers
3
Number of SATA III connectors
4
Number of storage drives supported
7
Number of water pump connectors
2
Package depth
294 mm
Package height
80 mm
Package weight
3555 g
Package width
345 mm
Parallel processing technology support
Not supported
PC health monitoring
FAN, Temperature, Voltage, Water cooling
PCI Express x16 (Gen 5.x) slots
1
Power source type
ATX
Processor manufacturer
AMD
Processor socket
Socket AM5
Product colour
White
Products per shipping (inner) case
1 pc(s)
RAID levels
1, 10
RAID support
Yes
RGB LED pin header
Yes
Screws included
Yes
Supported memory clock speed (max)
8000 MHz
Supported memory clock speeds
7000, 6800, 6666, 6600, 6400, 6200, 6000, 5600, 5200, 4800, 4400
Supported memory types
DDR5-SDRAM
Supported processor sockets
Socket AM5
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
System Management BIOS (SMBIOS) version
2.7
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
5
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
USB 3.2 Gen 2x2 connectors
1
VGA (D-Sub) ports quantity
0
Warranty period
3 year(s)
Wi-Fi
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Width
305 mm
WiFi-AP antenna jack
2
Windows operating systems supported
Windows 11 x64
