Motherboard ASRock SPC621D8-2L2T Intel C621A LGA 4189 ATX

Motherboard ASRock SPC621D8-2L2T Intel C621A LGA 4189 ATX
Motherboard ASRock SPC621D8-2L2T Intel C621A LGA 4189 ATX
Motherboard ASRock SPC621D8-2L2T Intel C621A LGA 4189 ATX
Motherboard ASRock SPC621D8-2L2T Intel C621A LGA 4189 ATX
Motherboard ASRock SPC621D8-2L2T Intel C621A LGA 4189 ATX
Motherboard ASRock SPC621D8-2L2T Intel C621A LGA 4189 ATX
Motherboard ASRock SPC621D8-2L2T Intel C621A LGA 4189 ATX
Motherboard ASRock SPC621D8-2L2T Intel C621A LGA 4189 ATX
R17,259
The ASRock SPC621D8-2L2T is a high-performance server motherboard built on the Intel C621A chipset, designed for demanding enterprise and data center workloads. It supports Intel Xeon processors with the LGA 4189 socket, delivering robust computing power and reliability for mission-critical applicat... Read More
Stock 3 Code 1187484 Brand ASROCK Model SPC621D8-2L2T Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, October 6
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The ASRock SPC621D8-2L2T is a high-performance server motherboard built on the Intel C621A chipset, designed for demanding enterprise and data center workloads. It supports Intel Xeon processors with the LGA 4189 socket, delivering robust computing power and reliability for mission-critical applications.

Key features

  • Supports Intel Xeon processors via LGA 4189 socket, ensuring top-tier performance for server tasks
  • Equipped with DDR4-SDRAM DIMM slots, operating at 1.2V for efficient memory handling
  • Integrated Aspeed AST2500 graphics controller with 16 MB onboard memory for basic display output
  • Features multiple LAN controllers including Intel I210, Intel X710-AT2, and Realtek RTL8211E for versatile networking
  • Supports storage interfaces M.2 and SATA III with RAID levels 0, 1, 5, and 10 for flexible data management
Key Highlights
  • Rack or tower servers for virtualization and compute workloads
  • Database servers requiring RAID-capable local storage
  • Networked storage and file servers with high-availability needs
  • Server platforms needing remote management and basic onboard graphics
  • Form factor: ATX
  • Chipset: Intel C621A
  • Processor socket: LGA 4189 for Intel Xeon processors
  • Memory support: DDR4-SDRAM, 8 DIMM slots, 1.2 V operation
  • Storage interfaces: M.2 and SATA III with support for RAID 0/1/5/10
  • Onboard graphics/controller: Aspeed AST2500 with 16 MB memory
  • Networking: Intel I210 and Intel X710-AT2 LAN controllers
Specifications
ATX Power connector (24-pin)
Yes
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Compatible processor series
Intel Xeon
Component for
Server
Depth
243.84 mm
EPS power connector (8-pin)
Yes
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
4
IPMI LAN (RJ-45) port
Yes
LAN controller
Realtek RTL8211E, Intel X710-AT2, Intel I210
Maximum number of SMP processors
1
Maximum RDIMM memory
64 GB
Memory slots type
DIMM
Memory voltage
1.2
Motherboard chipset
Intel C621A
Motherboard chipset family
Intel
Motherboard form factor
ATX
Number of memory slots
8
Number of SATA III connectors
8
On-board graphics card memory
16 MB
On-board graphics card model
Aspeed AST2500
Operating relative humidity (H-H)
20 - 90
Operating temperature (T-T)
10 - 35
PC health monitoring
Voltage, Temperature, FAN
PCI Express x16 (Gen 4.x) slots
4
Processor manufacturer
Intel
Processor socket
LGA 4189
RAID levels
10, 5, 1
RAID support
Yes
Storage temperature (T-T)
-40 - 70
Supported memory types
DDR4-SDRAM
Supported storage drive interfaces
SATA III, M.2
TPM connector
Yes
USB 2.0 connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) connectors
2
VGA (D-Sub) ports quantity
1
Wi-Fi
No
Width
304.8 mm

Leaflet

Open Leaflet
