Monitor Ernitec 0070-24155-L 24 inch LCD Display 1920x1080

The Ernitec 0070-24155-L is a 55" industrial-grade LED monitor designed for CCTV and surveillance applications. It offers a 4K UHD resolution of 3840 × 2160 with a 16:9 aspect ratio, a TFT-LED panel, 450 cd/m² brightness and a 4000:1 contrast ratio. The display provides wide 178° viewing angles, fast 5 ms response time and supports continuous 24/7 operation with an estimated lifetime of 50,000 hours. The metal chassis is engineered for durability with anti-static, anti-magnetic and anti-interference properties. Inputs include three HDMI 2.0 ports, one DisplayPort and one USB; the unit also includes stereo speakers and supports PAL/NTSC/SECAM video signals.

Advantages

This Ernitec monitor delivers high brightness, high contrast and high definition imaging tailored for CCTV use. It incorporates 3D digital filtering and noise reduction to improve picture clarity and fast image response to minimise motion artefacts. The robust metal enclosure and compatibility with VESA and stand mounting provide flexible installation options. Multi-language on-screen menus and a convenient controller simplify setup and daily operation.

Suitable for

• CCTV surveillance rooms and control centres
• Security monitoring stations and NVR/DVR workstations
• 24/7 operations requiring stable, long-life displays

Key specifications

• Screen size: 55"
• Active display area: 1209.6 × 680.4 mm
• Resolution: 3840 × 2160 (4K UHD)
• Aspect ratio: 16:9
• Panel type: TFT-LED
• Pixel pitch: 0.315 × 0.315 mm
• Brightness: 450 cd/m²
• Contrast ratio: 4000:1
• Viewing angle: 178° H / 178° V
• Response time: 5 ms
• Backlight: LED
• Inputs: HDMI 2.0 ×3, DP ×1, USB ×1
• Speakers: 2 × 3 W (stereo)
• Video formats: PAL / NTSC / SECAM
• Power: AC 100–240 V, 50/60 Hz; power consumption: 50 W
• Operating temperature: -30 to +85 °C
• Estimated lifetime: 50,000 hours
• VESA mount: 400 × 200 mm

How to use

Mount the monitor on a compatible stand or VESA bracket (400 × 200 mm). Connect video sources using HDMI 2.0 or DisplayPort as required and attach USB if using service or media functions. Power the unit from an AC 100–240 V supply. Use the on-screen menu and included controller to adjust brightness, contrast, position, clock/phase and colour settings; the display supports auto-adjust for standard video formats (PAL/NTSC/SECAM).

Recommendations

For continuous 24/7 surveillance, ensure adequate ventilation around the metal chassis and avoid strong magnetic fields. Use high-quality HDMI 2.0 or DisplayPort cables for 4K signals, and set the display brightness and contrast to levels appropriate for the control-room environment to extend component life.
