METZ CONNECT OpDAT Pigtail LC/APC Single Mode OS2 2m LSZH Yellow

The METZ CONNECT OpDAT Pigtail LC/APC is a high-quality fiber optic pigtail designed for indoor single-mode applications. It features a pre-terminated LC/APC connector on one end and unterminated stripped fiber on the other, allowing for field splicing or connectorization. The pigtail is manufactured with bend-insensitive fiber (ITU-T G.657.A1) and a 9/125 µm core/cladding diameter, ensuring low insertion loss and high return loss. The LSZH (Low Smoke Zero Halogen) jacket in yellow provides safety and easy identification.

Advantages

This pigtail offers excellent optical performance with typical insertion loss <0.3 dB and return loss >60 dB. The APC polish minimizes back reflection, making it ideal for high-speed networks. The bend-insensitive fiber allows for tight bends without signal degradation, simplifying installation in confined spaces.

Suitable for

• FTTx and LAN cabling
• Data centers and server rooms
• Telecommunication networks
• Indoor fiber optic distribution

Key specifications

• Product Type: Fiber Optic Pigtail
• Fiber Mode: Single Mode (OS2)
• Fiber Standard: ITU-T G.657.A1
• Core/Cladding: 9/125 µm
• Connector: LC/APC
• Other End: Unterminated (stripped fiber)
• Cable Length: 2 m
• Polish: APC
• Insertion Loss: <0.3 dB typical
• Return Loss: >60 dB typical
• Ferrule: Zirconia Ceramic
• Jacket Material: LSZH
• Jacket Color: Yellow
• Cable Diameter: 0.9 mm
• Min. Bend Radius: 7.5 mm
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Compliance: RoHS, REACH

Recommendations

For optimal performance, use with LC/APC adapters and ensure clean end faces before connection. Suitable for indoor use only.
