Metabo SB2 Suction Feed Spray Gun with 1.0 L Aluminium Cup, 1.5 mm Nozzle, Adjustable Spray Pattern, 3.5 bar 903063122

The Metabo SB2 pneumatic suction feed spray gun delivers professional-grade atomization for paints, varnishes, glazes, primers, wood preservatives, and plant protection agents. Its 1.5 mm precision nozzle and adjustable round/flat jet pattern ensure a smooth, even finish on surfaces large and small, while the 1.0 L aluminium cup provides ample capacity for continuous work.

Advantages

Built around a robust metal body, the SB2 offers independent material and air flow controls for fine-tuning spray output. The suction feed design draws coating directly from the cup, minimizing refill interruptions. A standard 1/4" air connection and 240 l/min air consumption make it compatible with most workshop compressors delivering at least 200 l/min continuous output.

Suitable for

• Applying paints and varnishes to furniture, doors, and trim
• Coating metal, wood, and masonry with primers and glazes
• Treating wood with preservatives or stains
• Dispensing plant protection agents in gardens and greenhouses
• Automotive touch-ups and small refinishing jobs

Key specifications

• Spray gun type: Suction feed
• Nozzle diameter: 1.5 mm
• Cup capacity: 1.0 L (aluminium)
• Maximum operating pressure: 3.5 bar
• Air consumption: 240 l/min
• Air connection thread: 1/4"
• Adjustable spray pattern: round and flat jet
• Material flow control: Yes
• Air flow control: Yes
• Body material: Metal

Recommendations

For best results, pair the SB2 with a compressor delivering at least 200 l/min continuous air flow and use a moisture trap to prevent finish defects. Clean the gun thoroughly after each use, especially when switching between solvent- and water-based materials.
