LEAN CARS AGM Gel Battery 12V 5Ah for 24V Vehicle

This LEAN CARS AGM gel battery is a high-performance, maintenance-free power source designed for vehicles requiring a 24V system with a 5Ah capacity. Built with advanced VRLA Gel technology and AGM separators, it delivers reliable, spill-proof operation and long service life. Ideal for small electric vehicles, UPS systems, alarm systems, emergency lighting, and medical devices.

Advantages

Sealed and maintenance-free design eliminates the need for water refilling. Gel electrolyte ensures safe operation in any position, while the valve-regulated construction prevents acid leakage. Low self-discharge rate (less than 3% per month) allows for extended storage without frequent recharging. High discharge current capability (75A for 5 seconds) supports demanding applications.

Suitable for

• Small electric vehicles (e.g., scooters, wheelchairs)
• UPS (Uninterruptible Power Supply) systems
• Alarm and security systems
• Emergency lighting
• Medical devices

Key specifications

• Battery Type: VRLA Gel (AGM)
• Nominal Voltage: 12V
• Nominal Capacity: 5Ah (C20)
• Terminal Type: F1 (Faston Tab 187)
• Max. Discharge Current: 75A (5 sec)
• Max. Charging Current: 1.5A
• Float Charge Voltage: 13.5V - 13.8V (at 25°C)
• Cyclic Charge Voltage: 14.4V - 14.7V (at 25°C)
• Internal Resistance: Approx. 30mΩ
• Operating Temperature Range (Discharge): -20°C to 60°C
• Operating Temperature Range (Charge): 0°C to 50°C
• Self-Discharge Rate: Less than 3% per month at 25°C
• Design Life: 5 years (standby use)
• Cycle Life: Up to 400 cycles at 50% DOD
• Construction: Sealed, Maintenance-Free
• Electrolyte: Gelified Sulfuric Acid
• Separator: Absorbed Glass Mat (AGM)
• Safety Features: Spill-proof, Valve Regulated
• Certifications: CE, RoHS

Recommendations

For optimal performance and longevity, use a compatible charger designed for VRLA Gel batteries. Avoid deep discharges below 50% DOD to maximize cycle life. Store in a cool, dry place when not in use.
