LASERWORLD CUBE 3 (51743257) - 800mW RGB Laser Show System

With a guaranteed 800mW of combined red, green, and blue laser output, the LASERWORLD CUBE 3 delivers professional-grade aerial effects in a compact aluminum housing. This Class 4 laser projector is built for clubs, mobile DJs, and event productions that demand brilliant beams and sharp graphics without the bulk of traditional systems.

Overview

The CUBE 3 integrates three diode laser sources—200mW red at 650nm, 70mW green at 520nm, and 530mW blue at 450nm—to produce a wide palette of colors. A high-speed scanner running at 28kpps @ 8° ILDA ensures smooth animations and tight beam alignment, while the 40° maximum scan angle covers large areas with ease. Control is flexible via DMX (12 channels), ILDA, sound-to-light, or auto mode with 128 pre-programmed patterns.

What stands out

• Guaranteed 800mW total output (1000mW typical) for intense, visible beams.
• True analog modulation for smooth color mixing and fades.
• Rugged aluminum chassis with active fan cooling for reliable operation.
• Comprehensive safety: key switch, interlock, and safety loop.
• Wide 85-250V AC power input for worldwide use without transformers.

Technical details

• Laser sources: Diode (red 650nm, green 520nm, blue 450nm).
• Scanner: 28kpps @ 8° ILDA, max scan angle 40°.
• Control: DMX512 (12 channels), ILDA, sound-to-light, auto.
• Pre-programmed patterns: 128.
• Beam diameter: approx. 3mm; divergence: 1.0mrad.
• Power supply: 85-250V AC, 30W consumption.
• Cooling: Fan; operating temperature 10-40°C.
• Housing: Aluminum; dimensions compact for easy rigging.

Our verdict

The CUBE 3 punches above its weight with professional scanning speed and robust safety features. It's an ideal centerpiece for small to medium venues seeking high-impact laser shows without the complexity of larger systems.
