Moving Head Wash EUROLITE TMH-X4 4x LED Zoom

The EUROLITE TMH-X4 4x LED Zoom is a compact moving head wash fixture designed for stage, club and event lighting. It integrates four high-power LEDs with a motorized zoom system to deliver flexible wash and beam effects. The fixture offers smooth pan and tilt movement, variable beam angle, and full-color mixing to create even illumination across performance areas. Easy DMX integration and standard mounting options make it suitable for fixed installations and rental setups.

Advantages

The TMH-X4 combines motorized zoom and four high-output LEDs to provide adjustable beam width and consistent color rendering. Smooth movement control enables precise positioning and dynamic effects without complex setup. Its compact size and standard rigging points simplify transport and installation, while DMX compatibility ensures straightforward integration into existing lighting rigs. Energy-efficient LED technology reduces power consumption and heat generation compared with traditional discharge fixtures.

Suitable for

Key specifications

How to use

Mount the fixture using the supplied yoke or secure it to truss points according to venue requirements and safety standards. Connect power and DMX cables, set the DMX address if used in a controlled rig, and select an operating mode appropriate to the setup. Use the motorized zoom to adjust beam width from tight beams to wide washes and position the head via pan and tilt to cover the target area. Adjust color mixing and intensity through DMX commands or onboard controls to achieve the desired wash and effect transitions.

Recommendations

For consistent performance, keep ventilation clear and allow adequate airflow around the fixture. Use DMX addressing and scenes for repeatable programming in live shows, and verify rigging hardware and cabling before each event. When used in rental or mobile setups, protect lenses and external surfaces during transport and inspect connectors regularly.
