Kaiser Elektro 9059-48 Cavity Wall Device Box - Black - 1 Piece - 15 cm

The Kaiser Elektro 9059-48 is a high-quality cavity wall device box designed for secure and professional installation of standard switches, sockets, and electronic devices. With a milling hole diameter of 68 mm and an installation depth of 48 mm, this box is ideal for drywall applications. Its airtight design ensures energy efficiency, while the halogen-free, flame-retardant material guarantees safety and compliance with DIN EN 60670-1.

Advantages

This device box offers exceptional versatility with 8 cable entry points (4x M20/M25 and 4x M20) and 2 screw domes for device mounting. The black color provides a neutral appearance, and the IP30 protection class makes it suitable for indoor use. The box can be combined horizontally and vertically, allowing flexible installation layouts.

Suitable for

• Standard switches and sockets
• Electronic devices in drywall
• Residential and commercial cavity wall installations

Key specifications

• Product Type: Cavity Wall Device Box
• Installation Method: Cavity Wall
• Milling Hole Diameter: 68 mm
• Installation Depth: 48 mm
• Device Screw Spacing: 60 mm
• Airtight Design: Yes
• Halogen-Free: Yes
• Material: High-Quality Plastic
• Color: Black
• IP Protection Class: IP30
• Number of Device Mounts: 2 (screw domes)
• Cable Entry Points: 8 (4x M20/M25, 4x M20)
• Combinability: Horizontal and Vertical
• Flame Retardant: Yes (Self-extinguishing)
• Operating Temperature: -5°C to +60°C
• Standard Compliance: DIN EN 60670-1
• Mounting Type (Device): Screw

Recommendations

For optimal performance, use with compatible switches and sockets. Ensure proper installation according to DIN EN 60670-1 guidelines. This product is part of the Kaiser Elektro range, known for reliability and innovation in electrical installation.
