Inter-Tech SA-1632WN PDU (power distribution unit) 16x C13 outlets, managed/monitored, 100–240V, 32A, TCP/IP, SNMP, black

The Inter-Tech SA-1632WN is a managed and monitored rack-mount PDU designed for distribution and remote control of power in server rooms, network cabinets and 19" IT racks. It provides sixteen C13 outlets and accepts an input voltage range of 100–240 V at up to 32 A, 50/60 Hz. The unit supports TCP/IP-based management through a web interface and SNMP, offers individual outlet switching, per-outlet current and voltage measurement, and environmental monitoring via the included temperature and humidity sensor. Physical dimensions and a black finish allow integration into standard racks while cascade input/output lets multiple PDUs be connected and controlled together.

Advantages

The SA-1632WN offers remote web- and SNMP-based monitoring and control, enabling administrators to switch each of the 16 C13 outlets individually and read real-time current, voltage and power values. Configurable warning thresholds and e-mail notifications support proactive management of power and environmental conditions. A cascade port simplifies centralized control of multiple PDUs, while the included sensor provides on-rack temperature and humidity data for improved infrastructure oversight. Support for HTTP/HTTPS and DHCP provides flexible network integration.

Suitable for

• Server rooms and data centres with rack-mounted equipment
• Network cabinets and telecommunications racks
• IT maintenance where remote outlet control and monitoring is required
• Environments that require environmental monitoring (temperature and humidity)

Key specifications

• Outlets: 16 × C13 AC sockets
• Input voltage: 100–240 V, 50/60 Hz
• Maximum input current: 32 A
• Maximum output power: up to 7360 W (dependent on input and load)
• Network protocols: TCP/IP, UDP, HTTP, HTTPS, DHCP, SNMP
• Remote management: web interface and SNMP (individual outlet switching and monitoring)
• Measurements: per-outlet current and voltage, total power monitoring
• Environmental monitoring: temperature and humidity sensor (included)
• Cascade: cascade input/output for linking multiple PDUs
• Mounting: 19" rack-compatible, black finish
• Dimensions: 1126 × 66 × 44.5 mm

How to use

Install the SA-1632WN in a standard 19" rack using the provided mounting hardware, connect the unit to mains power with a suitable CEE 1-32 plug and attach connected devices to the 16 C13 outlets. Configure network settings via DHCP or assign a static IP address, then access the built-in web interface over HTTP/HTTPS or manage the device using SNMP. Use the web interface to view real-time current and voltage readings, set warning thresholds, enable e-mail alerts, and switch outlets individually or in groups. If linking multiple units, connect the cascade ports to enable centralized control.

Recommendations

Monitor per-outlet current and set adjustable warning values before adding additional loads to ensure the total draw does not exceed the 32 A input rating. Place the included temperature and humidity sensor in a representative rack location for accurate environmental readings. Use HTTPS and strong user management settings to restrict remote access and enable e-mail notifications for critical alerts.
