HISMART TV993505 5G/LTE/CBRS 2x2 MIMO Panel Antenna, 1.7-4.2 GHz, 20 dBi & 22 dBi, IP67 Outdoor

Directional panel antenna engineered for 5G, LTE, and CBRS networks, delivering exceptional 2x2 MIMO performance across a wide 1.7-4.2 GHz frequency range. With peak gains of 20 dBi and 22 dBi on its two elements, the HISMART TV993505 ensures robust signal strength and improved data throughput for demanding outdoor environments.

Advantages

Dual slant ±45° polarization maximizes link reliability and MIMO efficiency. The UV-resistant ABS radome and IP67 ingress protection guarantee long-term durability in harsh weather. With a front-to-back ratio above 20 dB and port isolation greater than 25 dB, interference is minimized for cleaner transmission. The included pole/wall mounting kit simplifies installation, while the compact design supports wind survivability up to 200 km/h.

Suitable for

• Fixed wireless access (FWA) installations
• Rural and suburban broadband connectivity
• Enhancing 5G/LTE/CBRS router and CPE signal strength
• Point-to-point and point-to-multipoint backhaul
• Replacing outdated or low-gain antennas

Key specifications

• Antenna Type: Directional Panel Antenna
• MIMO Configuration: 2x2 MIMO
• Frequency Range: 1.7 GHz - 4.2 GHz
• Supported Technologies: 5G, LTE, CBRS
• Peak Gain: 20 dBi (Port 1), 22 dBi (Port 2)
• Polarization: Dual Slant ±45°
• Horizontal Beamwidth: 45°
• Vertical Beamwidth: 45°
• VSWR: < 1.5:1
• Input Impedance: 50 Ohm
• Connector Type: 2x N-Female
• Power Handling: 50 W
• Front-to-Back Ratio: > 20 dB
• Port-to-Port Isolation: > 25 dB
• Mounting Type: Pole/Wall Mount Kit (included)
• Radome Material: UV-Resistant ABS
• Operating Temperature: -40°C to +65°C
• Ingress Protection (IP) Rating: IP67
• Wind Survivability: 200 km/h

Recommendations

Ideal for fixed wireless access, rural broadband, and enhancing 5G/LTE/CBRS router signal strength in outdoor installations.
