Hikvision HiLook NVR-104MH-C(E) 4-Channel 8MP Network Video Recorder

The Hikvision HiLook NVR-104MH-C(E) is a 4-channel network video recorder designed for small to medium-sized surveillance systems. Supporting up to 8 MP resolution, it delivers high-quality video recording and playback. With H.265+ compression, it optimizes storage and bandwidth without compromising image clarity.

Advantages

This NVR offers reliable 4-channel IP video input with an incoming bandwidth of 40 Mbps and outgoing bandwidth of 60 Mbps. It supports simultaneous HDMI and VGA outputs, with HDMI up to 4K resolution. The device features a single SATA interface supporting hard drives up to 6 TB, providing ample storage for extended recording. Its compact design and low power consumption (≤10 W without HDD) make it ideal for energy-efficient setups.

Suitable for

• Small businesses and retail stores requiring up to 4 IP cameras
• Home surveillance systems with high-resolution cameras
• Remote monitoring applications via network connectivity

Key specifications

• Video Input: 4-channel IP
• Max Resolution: 8 MP
• Compression: H.265+/H.265/H.264+/H.264
• HDMI Output: Up to 4K (3840×2160)
• VGA Output: Up to 1920×1080
• SATA Interface: 1, up to 6 TB
• Network: 1x RJ45 10/100 Mbps
• USB: 2x USB 2.0
• Power: 12 VDC, ≤10 W
• Operating Temperature: -10°C to +55°C

Recommendations

For optimal performance, pair this NVR with HiLook or Hikvision IP cameras. Use a compatible hard drive (not included) for local storage. Ensure network stability for remote access via the HiLook app or Hik-Connect.
