Hikvision DS-K1T502DBWX-CQR Face Recognition Terminal with 7-inch Touch Screen, 2 MP Dual-Lens Camera, Fingerprint, Mifare Card, PIN, Wi-Fi, IP65, IK08

The Hikvision DS-K1T502DBWX-CQR is a high-performance face recognition terminal designed for secure and efficient access control. Featuring a 7-inch LCD touch screen and a 2 MP dual-lens camera with Wide Dynamic Range (WDR), it delivers clear image capture even in challenging lighting conditions. This terminal supports multiple authentication methods including face, fingerprint, Mifare card, and PIN, making it versatile for various security needs.

Advantages

With a deep learning algorithm, the DS-K1T502DBWX-CQR offers fast and accurate face recognition. It supports up to 50,000 face templates and 50,000 fingerprint templates, ensuring scalability for large organizations. The IP65 rating and IK08 vandal resistance make it suitable for both indoor and outdoor installations. Built-in Wi-Fi and TCP/IP connectivity simplify network integration.

Suitable for

• Corporate offices requiring high-security access control
• Government buildings and restricted areas
• Educational institutions and campuses
• Healthcare facilities
• Industrial sites and warehouses

Key specifications

• Display: 7-inch LCD touch screen
• Camera: 2 MP dual-lens with WDR
• Authentication: Face, fingerprint, Mifare card, PIN
• Face capacity: 50,000
• Fingerprint capacity: 50,000
• Card capacity: 100,000
• Event capacity: 500,000
• Communication: TCP/IP, Wi-Fi, RS-485, Wiegand, USB
• Power supply: 12 VDC / 3 A
• Ingress protection: IP65
• Vandal resistance: IK08
• Operating temperature: -30 °C to 60 °C
• Operating humidity: 0% to 90%

Recommendations

For optimal performance, install the terminal at a height of 1.5 meters and ensure adequate lighting. Pair with Hikvision access controllers for a complete solution. Regular cleaning of the camera lens and fingerprint sensor is recommended.
