Hikvision DS-3D504TP-A Unmanaged Industrial PoE Switch, 4 PoE+ Ports, 1 SFP Uplink, 60W Budget

The Hikvision DS-3D504TP-A is a robust unmanaged industrial PoE switch designed for reliable network connectivity in harsh environments. With 4 Gigabit PoE+ ports and 1 SFP uplink, it delivers power and data to IP cameras, access points, and other PoE devices, making it ideal for surveillance and industrial automation applications.

Advantages

This switch offers a total PoE power budget of 60W, with up to 30W per port, supporting IEEE 802.3af/at standards. Its rugged metal housing and wide operating temperature range (-30°C to 65°C) ensure stable performance in extreme conditions. The DIN-rail or wall-mountable design simplifies installation in control cabinets or on walls.

Suitable for

• IP surveillance systems (PoE cameras)
• Industrial automation networks
• Wireless access points and IoT devices
• Outdoor and harsh environment deployments

Key specifications

• 4 x 10/100/1000 Mbps PoE+ RJ45 ports
• 1 x 10/100/1000 Mbps RJ45 uplink, 1 x 1000 Mbps SFP slot
• Switching capacity: 12 Gbps
• Packet forwarding rate: 8.928 Mpps
• MAC address table: 8K entries
• Jumbo frame support: 10 KB
• Power input: DC 48-57V (redundant)
• Surge protection: 6KV on PoE ports
• ESD protection: 8KV contact, 15KV air
• Operating temperature: -30°C to 65°C
• Storage temperature: -40°C to 85°C
• Housing: Metal, DIN-rail / wall mount

Recommendations

For optimal performance, use with Hikvision PoE cameras and quality CAT5e or CAT6 cabling. Ensure adequate ventilation and power supply redundancy for critical installations.
