Hikmicro HIKVISION HM-TD1228T-3/G1/T3A Thermal Monocular

The Hikmicro HIKVISION HM-TD1228T-3/G1/T3A is a professional handheld thermal monocular designed for outdoor observation, security, and search and rescue operations. Combining a high-resolution thermal sensor with a visible light camera, it delivers clear imagery in complete darkness and adverse weather conditions. Built with a rugged IP67-rated housing, it withstands harsh environments and offers reliable performance.

Advantages

Equipped with a 384x288 thermal sensor and 35 mm lens, the device provides a detection range of up to 1800 m for a 1.7 m target. The integrated laser rangefinder measures distances up to 600 m with ±1 m accuracy. The OLED display with 1024x768 resolution ensures crisp image viewing. With Wi-Fi connectivity, users can stream or transfer data wirelessly. The replaceable 18650 Li-ion battery offers up to 5 hours of operation, and the 16 GB internal storage captures images and videos.

Suitable for

• Outdoor surveillance and security patrols
• Hunting and wildlife observation
• Search and rescue missions
• Law enforcement and tactical operations

Key specifications

• Thermal Sensor: 384x288 pixels, 12 μm pixel pitch
• NETD: < 35 mK (@25°C, F#=1.0)
• Frame Rate: 50 Hz
• Thermal Lens: 35 mm, 3.3x optical magnification
• Digital Zoom: 1x, 2x, 4x, 8x
• Detection Range: 1800 m (1.7 m target)
• Visible Camera: 1920x1080 pixels
• Display: OLED, 1024x768 pixels
• Color Palettes: Black Hot, White Hot, Red Hot, Fusion, Visible, Image Fusion
• Storage: 16 GB eMMC
• Wi-Fi: Yes
• Laser Rangefinder: Up to 600 m (accuracy ±1 m)
• Battery: Replaceable 18650 Li-ion, up to 5 hours (Wi-Fi off)
• Ingress Protection: IP67
• Operating Temperature: -30°C to 55°C

Recommendations

For optimal performance, use high-quality 18650 batteries and keep the lens clean. The device is ideal for professionals requiring reliable thermal imaging in demanding conditions.
