HellermannTyton KR 8-G5 Cable Clip White 100 Pieces

The HellermannTyton KR 8-G5 cable clip is a professional-grade solution for securing and routing cables in indoor environments. Made from high-quality polyamide 6.6, this clip offers excellent durability and flexibility, with a maximum bundle diameter of 8 mm. The white colour (RAL9010) ensures a clean, unobtrusive appearance, making it ideal for visible installations. Each pack contains 100 pieces, providing ample supply for medium to large projects.

Advantages

Easy to install with a hardened steel nail (2.0 mm diameter, 25 mm length) for secure fixing into wood, plaster, or masonry (pre-drilling recommended). Halogen-free and rated UL94 V2 for flammability, ensuring safety in various applications. Operating temperature range from -40 °C to +85 °C allows use in diverse conditions.

Suitable for

• Securing single cables or small bundles in electrical installations
• Indoor cable management in residential, commercial, and industrial settings
• Fixing cables to walls, ceilings, or baseboards

Key specifications

• Product Type: Cable Clip
• Series: KR
• Material: Polyamide 6.6 (PA66)
• Colour: White (RAL9010)
• Max. Bundle Diameter: 8 mm
• Mounting Type: Nail
• Nail Material: Hardened Steel
• Nail Diameter: 2.0 mm
• Nail Length: 25 mm
• Clip Length: 18.0 mm
• Clip Width: 10.0 mm
• Clip Height: 10.0 mm
• Operating Temperature: -40 °C to +85 °C
• Flammability Rating: UL94 V2
• Halogen-free: Yes
• UV Resistance: No
• Quantity per Pack: 100 Pieces
• Application Environment: Indoor
• Recommended Substrates: Wood, Plaster, Masonry (with pre-drilling)

Recommendations

For best results, pre-drill holes in masonry or hard surfaces. Ensure the nail is fully seated to avoid loosening. Suitable for use with cables up to 8 mm diameter.
