HellermannTyton Heat Shrink Tubing 28mm to 4.7mm Black 3:1 HFT-A

The HellermannTyton 151-28469 is a high-quality heat shrink tubing from the HFT-A series, designed for professional electrical insulation, mechanical protection, cable bundling, and strain relief. With a supplied internal diameter of 28 mm and a recovered internal diameter of 4.7 mm, this tubing offers a 3:1 shrink ratio, making it ideal for a wide range of applications. Made from cross-linked polyolefin, it is flexible, flame retardant (self-extinguishing), and UV resistant (black colour). It operates reliably in temperatures from -55°C to +135°C and requires a minimum shrink temperature of +90°C.

Advantages

This heat shrink tubing provides excellent dielectric strength (>20 kV/mm) and good chemical resistance against common fluids and solvents. It meets RoHS and UL 224 VW-1 standards, ensuring safety and compliance. The black colour offers UV protection, extending the life of the installation in outdoor or harsh environments.

Suitable for

• Electrical insulation of wires and cables
• Mechanical protection for connectors and terminals
• Cable bundling and organization
• Strain relief for cable assemblies
• Automotive, industrial, and marine applications

Key specifications

• Product Type: Heat Shrink Tubing
• Series: HFT-A
• Material: Cross-linked Polyolefin
• Colour: Black
• Supplied Internal Diameter: 28 mm
• Recovered Internal Diameter: 4.7 mm
• Shrink Ratio: 3:1
• Recovered Wall Thickness: 1.0 mm (approx.)
• Operating Temperature Range: -55°C to +135°C
• Minimum Shrink Temperature: +90°C
• Dielectric Strength: >20 kV/mm
• Flame Retardant: Yes (Self-extinguishing)
• UV Resistant: Yes (for black colour)
• Halogen Free: No
• Standards Met: RoHS, UL 224 VW-1
• Flexibility: Flexible
• Chemical Resistance: Good against common fluids and solvents

Recommendations

For best results, use a heat gun or hot air blower to shrink the tubing evenly. Ensure the surface is clean and dry before application. This product is suitable for both indoor and outdoor use where UV resistance is required.
