HellermannTyton HIS-3 Heat Shrink Tubing 3:1 6mm Black 1.2m

The HellermannTyton HIS-3 heat shrink tubing offers reliable insulation and protection for electrical connections. With a 3:1 shrink ratio, it fits a wide range of wire gauges and provides a tight, secure seal. Made from cross-linked polyolefin, this tubing is flexible, durable, and resistant to moisture and chemicals.

Advantages

High shrink ratio of 3:1 allows for versatile use on different cable diameters. Excellent dielectric strength and flame retardancy ensure safety in demanding environments. Easy to install with a minimum shrink temperature of +90°C.

Suitable for

• Electrical insulation of wires and cables
• Protection against moisture, chemicals, and abrasion
• Strain relief for connectors and terminals
• Color coding and identification of cables

Key specifications

• Product Type: Heat Shrink Tubing
• Series: HIS-3
• Material: Cross-linked Polyolefin (POX)
• Color: Black
• Shrink Ratio: 3:1
• Supplied Inner Diameter: 6 mm
• Recovered Inner Diameter: 2 mm
• Length: 1.2 m
• Minimum Shrink Temperature: +90 °C
• Operating Temperature Range: -55 °C to +125 °C
• Dielectric Strength: 20 kV/mm
• Flammability Rating: UL224 VW-1
• RoHS Compliant: Yes
• Packaging Unit: 1 piece

Recommendations

For best results, use a heat gun or hot air blower to evenly shrink the tubing. Ensure the cable surface is clean and dry before installation. Suitable for a wide range of applications including automotive, industrial, and electronic wiring.
