HAGER Residual Current Device 2P 40A 30mA Type AC CD241J

The HAGER CD241J is a high-quality add-on Residual Current Device (RCD) designed for use with Schneider Electric Acti 9 iC60 miniature circuit breakers. It provides reliable protection against earth leakage currents, ensuring safety in residential and commercial electrical installations. This 2-pole device is rated at 40A with a sensitivity of 30mA, making it suitable for a wide range of applications.

Advantages

Compact clip-on design for easy installation alongside MCBs. Complies with international standards IEC 61009-1 and IEC 61009-2-1. Robust construction with tunnel terminals for secure wiring. Suitable for use in distribution boards and electrical panels.

Suitable for

• Protection against earth leakage currents in electrical circuits
• Integration with Schneider Electric Acti 9 iC60 MCBs
• Residential and commercial electrical installations

Key specifications

• Product Type: Add-on Residual Current Device (RCD)
• Range: Acti 9
• Poles: 2P
• Rated Current (In): 40 A
• Earth Leakage Sensitivity (IΔn): 30 mA
• Earth Leakage Protection Type: AC type
• Rated Operational Voltage (Ue): 230 V AC 50/60 Hz
• Rated Insulation Voltage (Ui): 500 V AC 50/60 Hz
• Rated Impulse Withstand Voltage (Uimp): 6 kV
• Mounting Mode: Clip-on (right side of MCB)
• Terminal Type: Tunnel type terminals
• Terminal Capacity: 1 to 35 mm² (rigid), 1 to 25 mm² (flexible)
• Degree of Protection: IP20 (IP40 in enclosure)
• Operating Temperature: -5 to 60 °C
• Standards: IEC 61009-1, IEC 61009-2-1

Recommendations

For optimal performance, pair this RCD with a compatible Schneider Electric Acti 9 iC60 MCB. Ensure proper installation by a qualified electrician.
