GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4

GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4
GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4
GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4
GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4
GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4
36 mo.
GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4
GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4
GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4
GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4
GIGABYTE Motherboard X870M AORUS ELITE WIFI7 ICE — Micro ATX, AMD X870, Socket AM5, DDR5 up to 8200Hz (O.C), 14+2+2 VRM, PCIe 5.0, Wi‑Fi 7, 2.5 GbE, USB4
R5,552
GIGABYTE X870M AORUS ELITE WIFI7 ICE is a Micro ATX motherboard for Socket AM5 designed for AMD Ryzen 7000, 8000 and 9000 series processors. It combines a digital 14+2+2 phase VRM, four DDR5 DIMM slots supporting up to 256 GB and OC frequencies up to 8200 MT/s, PCIe 5.0 and PCIe 4.0 expansion, multi... Read More
Stock 4 Code 1724983 Brand GIGABYTE Model X870M A ELITE WF7 ICE Warranty 3 Years

Shipping & Returns

Estimated delivery Friday, October 2
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

GIGABYTE X870M AORUS ELITE WIFI7 ICE is a Micro ATX motherboard for Socket AM5 designed for AMD Ryzen 7000, 8000 and 9000 series processors. It combines a digital 14+2+2 phase VRM, four DDR5 DIMM slots supporting up to 256 GB and OC frequencies up to 8200 MT/s, PCIe 5.0 and PCIe 4.0 expansion, multiple M.2 and SATA storage options with RAID support, integrated 2.5 GbE LAN and Wi‑Fi 7 connectivity. The board targets compact high-performance desktop builds for gaming, content creation and productivity.

Advantages

The motherboard offers robust power delivery through a digital twin 14+2+2 VRM, broad memory support with DDR5 OC capability and four DIMM slots, and high-speed storage options including PCIe 5.0 M.2. Integrated networking includes 2.5 Gigabit Ethernet and Wi‑Fi 7, while dual USB4 Type‑C and HDMI provide modern connectivity. Additional convenience features such as EZ-Latch for tool-free PCIe and M.2 installation and a quick Wi‑Fi antenna EZ-Plug simplify assembly and upgrades.

Suitable for

  • High-performance gaming PCs in Micro ATX form factor
  • Content creation and video editing workstations
  • Compact productivity and multitasking desktop systems

Key specifications

  • Form factor: Micro ATX
  • Chipset: AMD X870
  • CPU socket: Socket AM5, supports AMD Ryzen 7000/8000/9000 series
  • Power design: Digital 14+2+2 phase VRM
  • Memory: 4× DDR5 DIMM slots, up to 256 GB, DDR5 OC up to 8200 MT/s, AMD EXPO support
  • Expansion: PCIe 5.0 x4 M.2 support, PCIe 5.0 and PCIe 4.0 slots
  • Storage: Multiple M.2 slots (including PCIe 5.0 x4), SATA III, RAID 0/1/5/10 support, up to 4 drives
  • Audio: 7.1 channel onboard audio codec
  • Networking: 2.5 GbE LAN and Wi‑Fi 7 (802.11be), Bluetooth 5.4
  • Rear I/O highlights: Dual USB4 Type‑C with DisplayPort Alt Mode, HDMI output
  • BIOS: UEFI AMI with Clear CMOS button and jumper

How to use

Install the motherboard into a compatible Micro ATX chassis and mount an AM5-compatible CPU with the appropriate cooler. Populate up to four DDR5 modules, install storage devices in M.2 or SATA slots and connect power from a PSU that meets your system's requirements. Attach Wi‑Fi antennae using the EZ-Plug, connect peripherals to USB4/USB and display outputs, then configure BIOS/UEFI settings for memory profiles (AMD EXPO) and storage RAID if required.

Recommendations

For stable high-frequency DDR5 operation and heavy CPU loads, use a quality power supply, a compatible high-performance CPU cooler, and ensure BIOS is updated to the latest version. When installing M.2 drives, follow the manufacturer's thermal guidance and use provided retention mechanisms for secure seating.
Key Highlights
  • X3D Turbo Mode: Unleash new era gaming performance
  • AMD Socket AM5: Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors
  • Digital twin 14+2+2 phases VRM solution
  • Dual Channel DDR5: DDR5 OC up to 8200MT/s. 4*DIMMs with AMD EXPO Memory Module Support
  • WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation
  • D5 Bionic Corsa for Infinite Memory Performance
  • EZ-Latch: PCIe and M.2 slots with Quick Release & Screwless Design
  • Ultra-Fast Storage: 2*M.2 slots, including PCIe 5.0 x4
  • Fast Networking: 2.5GbE LAN & Wi-Fi 7
  • Extended Connectivity: Dual USB4 Type-C with DP-Alt, HDMI
  • AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
  • PC micro ATX AMD X870 Realtek ALC1220-VB 7.1 channels
  • DDR5-SDRAM 4 DIMM Maximum internal memory: 256 GB
  • HDD & SSD M.2, PCI Express 4.0, PCI Express 5.0, SATA III RAID support Number of storage drives supported: 4
  • BIOS type: UEFI AMI 256 Mbit ACPI version: 5.0 Clear CMOS jumper Clear CMOS button
  • 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet Wi-Fi Wi-Fi 7 (802.11be) Bluetooth 5.4
Specifications
12V power connector
Yes
1st M.2 highest PCI Express generation
5.0
1st M.2 largest key size
25110
2nd M.2 highest PCI Express generation
4.0
2nd M.2 largest key size
22110
ACPI version
5.0
Antenna included
Yes
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC1220-VB
Audio output channels
7.1 channels
Batteries included
Yes
Battery capacity
220 mAh
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Battery weight
3 g
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.4
Bundled software
Norton® Internet Security (OEM version)
Clear CMOS button
Yes
Clear CMOS jumper
Yes
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Component for
PC
Cooling type
Passive
Country of origin
China
CPU fan connector
Yes
Depth
244 mm
Desktop Management Interface (DMI) version
2.7
Digital audio optical out
1
DirectX version
12.0
DisplayPort version
1.4
DVI-D ports quantity
0
ECC сompatibility
Non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
HDCP
Yes
HDCP version
2.3
HDMI ports quantity
1
HDMI version
2.1
Headphone outputs
1
Height
35 mm
LAN controller
Realtek RTL8125
Line-in
Yes
Lithium weight per battery
0.07 g
Maximum internal memory
256 GB
Maximum internal memory per slot
64 GB
Maximum resolution
4096 x 2160 pixels
Memory channels
Dual-channel
Memory slots type
DIMM
Motherboard chipset
AMD X870
Motherboard chipset family
AMD
Motherboard form factor
micro ATX
Number of battery cells
1
Number of chassis fan connectors
4
Number of CPU fan connectors
2
Number of EPS power connectors (8-pin)
1
Number of HDDs supported
2
Number of M.2 (M) slots
2
Number of memory slots
4
Number of RGB LED pin headers
4
Number of SATA III connectors
2
Number of storage drives supported
4
Number of water pump connectors
2
Package depth
268 mm
Package height
68 mm
Package weight
2.06 kg
Package width
270 mm
Parallel processing technology support
Not supported
PC health monitoring
Fan, Temperature, Voltage, Water cooling
PCI Express x16 (Gen 4.x) slots
1
PCI Express x16 (Gen 5.x) slots
1
Power source type
ATX
Processor manufacturer
AMD
Processor socket
Socket AM5
Product colour
White
Products per shipping (inner) case
1 pc(s)
RAID levels
0, 1, 5, 10
RAID support
Yes
RGB LED pin header
Yes
S/PDIF out port
Yes
Screws included
Yes
Supported memory clock speed (max)
8200 MHz
Supported memory clock speeds
8200,8000,7950,7900,7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5200,4800,4400 MHz
Supported memory types
DDR5-SDRAM
Supported processor sockets
Socket AM5
Supported storage drive interfaces
M.2, PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive types
HDD & SSD
System Management BIOS (SMBIOS) version
2.7
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
USB 3.2 Gen 2x2 connectors
1
USB4 Gen 3x2 ports quantity
2
VGA (D-Sub) ports quantity
0
Warranty period
3 year(s)
Weight
1.86 kg
Wi-Fi
Yes
Wi-Fi standards
Wi-Fi 7 (802.11be)
Width
244 mm
WiFi-AP antenna jack
2
Windows operating systems supported
Windows 11 x64
WLAN controller model
Realtek RTL8922AE

Leaflet

Open Leaflet
