Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX

Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX
Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX
Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX
Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX
Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX
36 mo.
Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX
Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX
Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX
Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX
Motherboard GIGABYTE B850 AORUS ELITE WIFI7 ICE, B850, AM5, ATX
R4,371
The GIGABYTE B850 AORUS ELITE WIFI7 ICE is an ATX motherboard for Socket AM5 systems, designed to support AMD Ryzen 9000 Series processors. It features an AMD B850 chipset, a 12+2+1 digital VRM power stage configuration for stable CPU delivery, four DDR5 memory slots with support up to 8200 MHz (OC)... Read More
Stock 1 Code 30150 Brand GIGABYTE Model B850 A ELITE WF7 ICE Warranty 3 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The GIGABYTE B850 AORUS ELITE WIFI7 ICE is an ATX motherboard for Socket AM5 systems, designed to support AMD Ryzen 9000 Series processors. It features an AMD B850 chipset, a 12+2+1 digital VRM power stage configuration for stable CPU delivery, four DDR5 memory slots with support up to 8200 MHz (OC) and a maximum capacity of 256 GB, as well as multiple high-speed storage and expansion options including one PCIe 5.0 slot and two PCIe 4.0 M.2 slots. Onboard connectivity includes 2.5 GbE LAN and Wi‑Fi 7 for modern networking needs.

Advantages

The board combines a robust power design with modern connectivity to provide reliable performance for demanding tasks. DDR5 memory support and high overclocking headroom enable improved system responsiveness, while PCIe 5.0 and dual PCIe 4.0 M.2 slots offer versatile, high-throughput storage and expansion capabilities. Integrated 2.5 GbE and Wi‑Fi 7 simplify networking for gaming, content creation, and professional workflows.

Suitable for

  • Gaming PCs requiring high CPU and memory performance
  • Content creation and video editing workstations
  • Productivity and professional systems needing fast storage and networking

Key specifications

  • Form factor: ATX
  • Chipset: AMD B850
  • Processor socket: Socket AM5 (supports AMD Ryzen 9000 Series)
  • Memory: 4× DDR5 slots, up to 8200 MHz (OC), maximum 256 GB
  • Power design: 12+2+1 digital VRM
  • Expansion: 1× PCIe 5.0 slot
  • Storage: 2× PCIe 4.0 M.2 slots (NVMe), RAID support
  • Networking: 2.5 GbE LAN, Wi‑Fi 7
  • Weight: 2.16 kg

How to use

Install the motherboard in a compatible ATX case and mount an AMD Ryzen 9000 Series CPU into the Socket AM5 following the CPU and cooler manufacturer instructions. Populate up to four DDR5 memory modules, install storage devices into the M.2 and SATA connectors as required, and connect power from a suitable PSU to the 24-pin ATX and CPU power headers. Configure BIOS settings for memory frequency, RAID, and boot order as needed. Install drivers and utilities from GIGABYTE to enable full functionality of networking and chipset features.

Recommendations

For stable overclocking and long-term reliability, use a high-quality power supply and an adequate CPU cooling solution; keep BIOS and device drivers updated to the latest versions provided by GIGABYTE.
Key Highlights
  • Twin 14+2+2 Phases Digital VRM with DrMOS
  • Dual Channel DDR5:4*DIMMs
  • PCIe Gen5 x16 with PCIe UD Slot & EZ-Latch Plus
  • M.2 Gen5 with EZ-Latch Plus, Fully Covered MOSFET Heatsinks
  • Wi-Fi 7 with WIFI EZ-Plug & Directional Antenna
  • 2.5GbE LAN, Q-Flash Plus
  • AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
  • PC ATX AMD B850 Realtek ALC897 7.1 channels
  • DDR5-SDRAM 4 DIMM Maximum internal memory: 256 GB
  • HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 7
  • BIOS type: UEFI AMI 256 Mbit ACPI version: 5.0 Clear CMOS jumper Clear CMOS button
  • 2.5 Gigabit Ethernet Wi-Fi Wi-Fi 7 (802.11be) Bluetooth 5.4
Specifications
12V power connector
Yes
1st M.2 highest PCI Express generation
5.0
1st M.2 largest key size
25110
2nd M.2 highest PCI Express generation
4.0
2nd M.2 largest key size
22110
3rd M.2 highest PCI Express generation
4.0
3rd M.2 largest key size
22110
ACPI version
5.0
Antenna included
Yes
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC897
Audio output channels
7.1 channels
Batteries included
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Battery weight
3 g
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.4
Bundled software
Norton Internet Security (OEM version) LAN bandwidth management software
Clear CMOS button
Yes
Clear CMOS jumper
Yes
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Component for
PC
Country of origin
China
CPU fan connector
Yes
Depth
244 mm
Desktop Management Interface (DMI) version
2.7
DirectX version
12.0
DisplayPort version
1.4
DisplayPorts quantity
1
DVI-D ports quantity
0
ECC сompatibility
Non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
HDCP
Yes
HDMI ports quantity
1
HDMI version
1.4
Headphone outputs
1
Height
35 mm
Lithium weight per battery
0.07 g
Maximum internal memory
256 GB
Maximum internal memory per slot
64 GB
Maximum resolution
4096 x 2160 pixels
Memory channels
Dual-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
AMD B850
Motherboard chipset family
AMD
Motherboard form factor
ATX
mSATA ports quantity
0
Number of battery cells
1
Number of chassis fan connectors
3
Number of CPU fan connectors
2
Number of EPS power connectors (8-pin)
1
Number of HDDs supported
4
Number of M.2 (M) slots
3
Number of memory slots
4
Number of RGB LED pin headers
4
Number of SATA connectors
0
Number of SATA II connectors
0
Number of SATA III connectors
4
Number of storage drives supported
7
Number of water pump connectors
2
On-board graphics card
No
Package depth
270 mm
Package height
80 mm
Package weight
2.46 kg
Package width
335 mm
Parallel processing technology support
Not supported
PC health monitoring
Fan, Temperature, Voltage, Water cooling
PCI Express x16 (Gen 4.x) slots
2
Peripheral (Molex) power connectors (4-pin)
1
Power source type
ATX
Processor manufacturer
AMD
Processor socket
Socket AM5
Product colour
Brown, White
Products per shipping (inner) case
1 pc(s)
RAID levels
0, 1, 10
RAID support
Yes
RGB LED pin header
Yes
Screws included
Yes
Serial port headers
1
Supported memory clock speed (max)
8200 MHz
Supported memory clock speeds
4400,4800,5200,5600,5800,6000,6200,6600,6800,7000,7200,7400,7600,7900,7950,8000,8200 MHz
Supported memory types
DDR5-SDRAM
Supported processor sockets
Socket AM5
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
System Management BIOS (SMBIOS) version
2.7
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Total number of SATA connectors
4
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
5
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
USB 3.2 Gen 2x2 connectors
1
VGA (D-Sub) ports quantity
0
Warranty period
3 year(s)
Weight
2.16 kg
Wi-Fi
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Width
305 mm
WiFi-AP antenna jack
2
Windows operating systems supported
Windows 10 x64, Windows 11 x64
WLAN controller model
Realtek RTL8922AE

Manual

Open Manual

Leaflet

Open Leaflet
