GIGABYTE B650E EAGLE AM5 ATX Motherboard, DDR5, PCIe 5.0, 2.5GbE, Wi-Fi 6E

The GIGABYTE B650E EAGLE stands apart from typical mid-range boards by pairing AMD's B650E chipset with a genuine PCIe 5.0 x16 slot and a PCIe 5.0 M.2 connector — a combination usually reserved for pricier X670E models. This ATX board is built for AM5 processors, offering four DDR5 DIMM slots with support for up to 192 GB of memory and overclocked speeds reaching DDR5 8000 MHz. A 14+2+1 phase digital VRM keeps power delivery stable for Ryzen 7000 and 8000 series CPUs, while the extensive rear I/O includes USB 3.2 Gen 2x2 Type-C, HDMI 2.1, and DisplayPort 1.4. Networking is handled by Realtek 2.5GbE LAN and AMD Wi-Fi 6E with Bluetooth 5.2, ensuring fast wired and wireless connectivity. Storage options include three M.2 slots (one PCIe 5.0 x4 and two PCIe 4.0 x4) plus four SATA 6 Gb/s ports, giving you flexibility for high-speed NVMe drives and traditional SSDs or HDDs. The board's black PCB and subtle silver accents fit cleanly into most builds, and the AMI UEFI BIOS with 256 Mbit flash provides a user-friendly interface for tuning and updates.

Highlights

• AMD AM5 socket for Ryzen 7000/8000 series processors
• AMD B650E chipset with PCIe 5.0 support for graphics and M.2 storage
• 4x DDR5 DIMM slots, up to 192 GB, speeds up to DDR5 8000 (OC)
• 1x PCIe 5.0 x16, 1x PCIe 4.0 x4, 1x PCIe 3.0 x2 expansion slots
• 1x M.2 PCIe 5.0 x4, 2x M.2 PCIe 4.0 x4, 4x SATA 6 Gb/s
• Realtek 2.5GbE LAN, AMD Wi-Fi 6E, Bluetooth 5.2
• Rear USB: 1x USB 3.2 Gen 2x2 Type-C, 3x USB 3.2 Gen 2 Type-A, 5x USB 3.2 Gen 1 Type-A, 4x USB 2.0
• HDMI 2.1 and DisplayPort 1.4 outputs
• 14+2+1 phases digital VRM for stable power
• ATX form factor, black colour

In daily use

The B650E EAGLE handles everything from gaming to content creation without breaking a sweat. The PCIe 5.0 x16 slot is ready for next-generation graphics cards, while the PCIe 5.0 M.2 slot supports the fastest NVMe SSDs for near-instant load times. With four DDR5 slots, you can start with 32 GB and expand up to 192 GB as your needs grow. The 2.5GbE LAN and Wi-Fi 6E ensure low-latency online gaming and rapid file transfers, even in crowded networks. The rear USB selection covers high-speed peripherals, external drives, and legacy devices, and the HDMI 2.1 port can drive 4K displays at high refresh rates. The UEFI BIOS is straightforward for both beginners and enthusiasts, with easy access to XMP/EXPO profiles for memory overclocking.

Full specifications

• CPU Socket: AMD AM5
• Chipset: AMD B650E
• Form Factor: ATX
• Memory: 4x DDR5 DIMM, max 192 GB, up to DDR5 8000 (OC)
• Expansion Slots: 1x PCIe 5.0 x16, 1x PCIe 4.0 x4, 1x PCIe 3.0 x2
• Storage: 1x M.2 PCIe 5.0 x4, 2x M.2 PCIe 4.0 x4, 4x SATA 6 Gb/s
• LAN: Realtek 2.5GbE
• Wireless: AMD Wi-Fi 6E RZ616, Bluetooth 5.2
• Audio: Realtek ALC897 codec
• Rear USB: 1x USB 3.2 Gen 2x2 Type-C, 3x USB 3.2 Gen 2 Type-A, 5x USB 3.2 Gen 1 Type-A, 4x USB 2.0/1.1 Type-A
• Video Outputs: 1x HDMI 2.1, 1x DisplayPort 1.4
• Power Connectors: 1x 24-pin ATX, 2x 8-pin EPS
• VRM: 14+2+1 phases digital
• BIOS: 256 Mbit flash, AMI UEFI BIOS

Final note

The GIGABYTE B650E EAGLE delivers future-ready PCIe 5.0 and robust power delivery at a price that undercuts many X670E boards, making it an excellent foundation for a high-performance AM5 build.
