GETFORT GF-518 Wood, Metal and AC Voltage Detector

The GETFORT GF-518 is a versatile 3-in-1 detector designed to locate wood, metal (ferrous and non-ferrous), and live AC voltage wires behind walls, floors, and ceilings. Ideal for DIY enthusiasts and professionals, it ensures safe drilling and cutting by identifying hidden hazards.

Advantages

Multi-purpose detection saves time and increases safety. Automatic calibration and clear LCD backlit display with audible and visual alerts make operation simple. Compact and lightweight, powered by a standard 9V battery.

Suitable for

• Locating wooden studs for mounting shelves or fixtures
• Detecting metal pipes or rebar before drilling
• Identifying live AC cables to avoid electric shock

Key specifications

• Detection types: Wood, Ferrous Metal, Non-Ferrous Metal, AC Voltage
• Max wood detection depth: 38 mm (1.5 in)
• Max ferrous metal depth: 120 mm (4.7 in)
• Max non-ferrous metal depth: 80 mm (3.1 in)
• Max AC voltage depth: 50 mm (2 in)
• Display: LCD with backlight
• Power: 1x 9V (6F22) battery (not included)
• Auto power-off: Yes
• Calibration: Automatic
• Operating temperature: -10°C to 50°C
• Storage temperature: -20°C to 70°C
• Humidity: < 75% RH
• Indication: Audible beep and visual LCD
• Detection modes: 3 (Wood, Metal, AC Voltage)
• Low battery indicator: Yes

Recommendations

Always verify detection by moving the device slowly. For best results, calibrate on a known non-metallic surface. Not suitable for detecting wires behind metal cladding.
