ESPE HDN-3024 DIN Rail Power Supply 24V 30W 1.25A

The ESPE HDN-3024 is a high-efficiency switching mode power supply designed for DIN rail mounting. It provides a stable 24V DC output with 30W power and 1.25A current, ideal for industrial automation, control systems, and building automation applications. With a compact plastic enclosure and screw terminal connections, it ensures reliable performance in demanding environments.

Advantages

High efficiency of 87% reduces energy loss and heat generation. Wide input voltage range (90-264V AC / 127-370V DC) ensures global compatibility. Built-in protection features (short circuit, overload, over voltage) safeguard connected equipment. Compact 22.5mm width saves space on DIN rails.

Suitable for

• Industrial control panels
• Building automation systems
• PLC and sensor power supply
• Security and access control systems

Key specifications

• Output: 24V DC, 1.25A, 30W
• Input: 90-264V AC / 127-370V DC, 47-63Hz
• Efficiency: 87%
• Mounting: DIN Rail TS-35/7.5 or TS-35/15
• Operating temperature: -20°C to +70°C
• Dimensions: 22.5 x 90 x 100 mm (WxHxD)
• Weight: 0.2 kg
• Protection: Short circuit, overload, over voltage
• Certifications: CE, RoHS

Recommendations

For optimal performance, ensure adequate ventilation and do not exceed the rated output. Suitable for use with ESPE and compatible DIN rail accessories.
