TDK Grenton 24VDC 1.25A DIN Rail Power Supply Module PSU-241-2-01

The TDK Grenton PSU-241-2-01 is a high-efficiency DIN rail power supply module delivering a stable 24 VDC output at 1.25 A (30 W). Designed for industrial automation, building management, and control systems, this compact 2-module unit ensures reliable power conversion from 100-240 VAC input with natural convection cooling and comprehensive protection features.

Advantages

Compact 2-module DIN rail design saves space in control cabinets. High efficiency >85% reduces energy loss and heat generation. Built-in overload, short circuit, and overvoltage protection safeguard connected equipment. LED power indicator for quick status checks. Screw terminal connections ensure secure wiring.

Suitable for

• Industrial control panels
• Building automation systems
• PLC and sensor power supplies
• HVAC controllers
• Security and access control systems

Key specifications

• Input: 100-240 VAC, 50/60 Hz
• Output: 24 VDC, 1.25 A, 30 W
• Mounting: DIN Rail (2 modules)
• Efficiency: >85%
• Protection: Overload, Short Circuit, Overvoltage
• Operating Temperature: -10°C to +50°C
• Cooling: Natural Convection
• Connection: Screw Terminals
• Ripple & Noise: <100 mVp-p
• Certifications: CE

Recommendations

For optimal performance, use with appropriate circuit protection and ensure adequate ventilation. Suitable for use in dry indoor environments only.
