EMITER EM/AH6515 15U Wall-Mount Network Cabinet 600x550x770 mm, Tempered Glass Door, Black

For installations where floor space is at a premium, the EMITER EM/AH6515 split hanging cabinet delivers a secure 15U enclosure that mounts directly to the wall, keeping your networking hardware organized and protected without sacrificing room. Its 600 mm width and 550 mm depth accommodate standard 19-inch equipment, while the combination of a tempered glass front door and removable sheet metal side panels offers both visibility and easy access during setup or maintenance.

Highlights

• 15U rack capacity for switches, patch panels, and servers
• Wall-mount design frees up floor space in offices, retail, or industrial settings
• Tempered glass front door with lock for security and visual monitoring of equipment status
• Removable sheet metal side panels simplify cable routing and equipment installation
• Adjustable mounting rails support various equipment depths
• Top and bottom cable entry points with knockouts for clean cable management
• Durable steel construction with powder-coated finish in black
• IP20 rating for indoor use

In daily use

Mounting the EM/AH6515 is straightforward thanks to its sturdy steel frame and pre-drilled wall-mounting points. Once installed, the lockable glass door allows quick visual checks of LED indicators without opening the cabinet, while the 180-degree door opening provides full access when needed. The removable side panels can be taken off entirely during initial equipment installation, then reattached to maintain a clean, professional appearance. Cable entry from both top and bottom ensures flexible routing for power and data lines.

Full specifications

• Rack Standard: 19-inch
• Rack Units (U): 15U
• External Dimensions (WxDxH): 600 x 550 x 770 mm
• Mounting Type: Wall Mount
• Front Door Type: Tempered Glass
• Side Panels: Removable Sheet Metal
• Material: Steel
• Security: Lockable Front Door
• Adjustable Mounting Rails: Yes
• Cable Entry Points: Top and Bottom
• Door Opening Angle: 180 degrees
• Finish: Powder Coated
• Color: Black
• IP Rating: IP20

Final note

The EMITER EM/AH6515 combines space-saving wall mounting with robust steel construction and a lockable glass door, making it an ideal choice for secure and organized network installations in constrained environments.
