Electrical Box for Insulation KUZ-VOI-KB - Installation Box for ETICS, Halogen-Free PP, Orange

The KUZ-VOI-KB Electrical Box for Insulation is a high-quality installation box designed specifically for External Thermal Insulation Composite Systems (ETICS). Manufactured from halogen-free polypropylene (PP), this box ensures safety and durability in demanding environments. It is compatible with insulation thicknesses from 100 mm to 250 mm and offers an adjustable installation depth of up to 200 mm. The box features pre-marked conduit entries for Ø20 mm and Ø25 mm, making it versatile for various wiring needs. With a maximum load capacity of 400 g, it is suitable for mounting light fixtures, motion sensors, cameras, and outdoor sockets, including 400V applications. The product is self-extinguishing, UV-stable, and has an IP30 protection rating. It complies with EN 60670-1 and EN 60670-22 standards. Package includes the installation box, internal carrier plate, and screws for device mounting.

Advantages

Halogen-free material ensures safety in case of fire. Adjustable depth accommodates various insulation thicknesses. Pre-marked conduit entries simplify installation. High load capacity supports a wide range of devices. UV-stable and temperature-resistant for outdoor use.

Suitable for

• External Thermal Insulation Composite Systems (ETICS)
• Mounting light fixtures, motion sensors, cameras, and outdoor sockets
• 400V applications

Key specifications

• Product Type: Installation Box for Thermal Insulation
• Material: Halogen-free Polypropylene (PP)
• Insulation Thickness Compatibility: 100 mm to 250 mm
• Installation Depth: Up to 200 mm (Adjustable)
• Conduit Entry Diameter: Ø20 mm / Ø25 mm (Pre-marked)
• Maximum Load Capacity: 400 g
• Temperature Resistance: -25 °C to +60 °C
• Protection Rating: IP30
• Flame Retardancy: Self-extinguishing
• Halogen-Free: Yes
• UV Stability: Yes
• Color: Orange
• Mounting Type: Flush-mounted
• Compliance Standards: EN 60670-1, EN 60670-22

Recommendations

For optimal performance, ensure the insulation thickness is within the specified range and use appropriate conduit sizes. The box is designed for flush mounting in ETICS systems.
