EFB ICS IE UC900 SS23 Cat.7 Industrial Ethernet Cable, S/FTP, PE, Black, Armored, UV-Resistant

The EFB ICS IE UC900 SS23 Cat.7 Industrial Ethernet Cable is a high-performance data cable designed for demanding industrial and outdoor applications. Manufactured by DRAKA, this cable features a robust construction with steel wire braid armoring and a UV-resistant PE jacket, ensuring reliable data transmission in harsh environments. With Cat.7 performance, it supports up to 10 Gigabit Ethernet over 4 pairs of AWG 23/1 solid bare copper conductors, S/FTP shielding, and a frequency range up to 900 MHz.

Advantages

This cable offers exceptional durability and signal integrity. The steel wire braid armoring provides mechanical protection against crushing and impact, while the UV-resistant PE jacket allows for outdoor and direct burial use. The S/FTP shielding minimizes electromagnetic interference, ensuring stable data transmission even in electrically noisy industrial settings.

Suitable for

• Industrial Ethernet networks (PROFINET, EtherCAT, etc.)
• Outdoor installations and direct burial
• Data centers and server rooms requiring high-speed connections
• Automation and control systems

Key specifications

• Cable Category: Cat.7 (Class F)
• Shielding: S/FTP (Screened/Foiled Twisted Pair)
• Conductor: AWG 23/1 solid bare copper
• Number of Pairs: 4
• Jacket Material: PE (Polyethylene), black
• Armoring: Steel wire braid
• UV Resistance: Yes
• Impedance: 100 Ohm ± 5 Ohm
• Max. Frequency: 900 MHz
• Data Rate: Up to 10 Gbit/s (10GBASE-T)
• Outer Diameter: 11.5 mm
• Operating Temperature: -20°C to +60°C
• Standards: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2

Recommendations

For optimal performance, use with Cat.7 compatible connectors and ensure proper grounding of the shielding. This cable is ideal for fixed installations in industrial environments where mechanical strength and environmental resistance are required.
