EFB Elektronik ECOFIBER Fiber Optic Patch Cable SC/APC Singlemode (OS2) 1m Yellow

The EFB Elektronik ECOFIBER fiber optic patch cable is a high-performance singlemode (OS2) connection solution designed for reliable data transmission in indoor networks. With SC/APC connectors on both ends and a simplex 1-fiber construction, this cable ensures low insertion loss and high return loss, making it ideal for FTTH, CATV, and telecommunication applications.

Advantages

This cable offers exceptional signal integrity with typical insertion loss < 0.3 dB and return loss > 60 dB. The LSZH (Low Smoke Zero Halogen) jacket provides enhanced safety in case of fire, reducing toxic fumes. Its yellow color allows easy identification as a singlemode fiber.

Suitable for

• Fiber-to-the-home (FTTH) installations
• CATV networks
• Telecommunication and data center connections
• Indoor backbone cabling

Key specifications

• Connector Type: SC/APC (Male) to SC/APC (Male)
• Fiber Mode: Singlemode (OS2)
• Fiber Count: Simplex (1 Fiber)
• Cable Length: 1 meter
• Core/Cladding: 9/125 µm
• Jacket Material: LSZH
• Cable Color: Yellow
• Polish Type: APC (Angled Physical Contact)
• Insertion Loss: < 0.3 dB (typical)
• Return Loss: > 60 dB (typical)
• Operating Temperature: -20°C to 70°C
• Compliance: RoHS, CE

Recommendations

For optimal performance, ensure connectors are clean before installation. Use appropriate patch panels and splicing equipment. This cable is not suitable for outdoor use without additional protection.
