Eaton HotSwap MBP 6000i G2 Maintenance Bypass Panel 6000 VA 3U Rack-Mountable

The Eaton HotSwap MBP 6000i G2 is a professional maintenance bypass panel designed for uninterrupted power supply (UPS) systems. It allows safe and easy replacement or servicing of UPS units without powering down connected equipment. With a robust 6000 VA capacity and 3U rack-mountable form factor, it is ideal for data centers, server rooms, and critical infrastructure.

Advantages

Hot-swap capability enables UPS maintenance without downtime. Manual bypass switch ensures safe isolation. Compact 3U design saves rack space. Compatible with Eaton 9PX, 9SX, and 5PX UPS series.

Suitable for

• Data centers requiring high availability
• Server rooms with Eaton UPS systems
• Industrial applications needing UPS redundancy
• IT professionals performing routine UPS maintenance

Key specifications

• Power Capacity: 6000 VA
• Input Voltage: 200-240 V AC
• Output Voltage: 200-240 V AC
• Output Connections: 6 x IEC 320 C13 + 2 x IEC 320 C19
• Input Connection: Hardwired (Terminal Block)
• Maximum Current: 30 A
• Form Factor: 3U Rack-Mountable / External
• Bypass Type: Manual
• Phase: Single Phase
• Operating Temperature: 0 - 40 °C
• Humidity: 0 - 95% (non-condensing)
• Certifications: CE, EAC, RCM, UKCA

Recommendations

For optimal performance, pair with Eaton 9PX or 9SX UPS. Ensure proper ventilation and load balancing. Professional installation recommended.
