Diodenkabel ShiverPeaks 30101, 5-pin 0.2 m cable for signal/LED connections

Diodenkabel ShiverPeaks 30101, 5-pin 0.2 m cable for signal/LED connections is a short, flexible five-conductor connection cable intended for diodes, LEDs and other low-voltage signal applications. The cable provides a compact connection solution with five insulated conductors in a single sheath and is designed for simple plug-in wiring where space is limited and precise connector pairing is required. It is suitable for audio/video, lighting and control projects that need a reliable short link between signal sources and diodes or indicator LEDs.

Advantages

The 0.2 m length minimises excess wiring in compact installations while providing five separate conductors for independent signal or power lines. Its flexible construction allows easy routing in tight spaces and supports straightforward plug-in connections. The cable’s design focuses on reliable signal transmission for low-voltage diode and LED circuits and reduces clutter compared with multiple single-core leads.

Suitable for

• Connecting LEDs and indicator diodes to control boards or audio/video equipment
• Short signal runs in lighting fixtures and stage equipment
• Compact installations where limited space requires short, flexible cabling

Key specifications

• Number of conductors: 5
• Length: 0.2 m
• Intended use: low-voltage signal and LED/diode connections
• Construction: flexible multi-conductor cable with individual insulated cores

How to use

Match the five conductors to the corresponding terminals or connectors on the device and the LED or diode assembly, observing polarity where applicable. Route the cable to avoid sharp bends and stress points, and insert the connectors into the mating sockets for a firm plug-in connection. For secure and long-lasting installations, ensure contacts are clean and connectors are fully seated during assembly.

Recommendations

Use this cable for short-distance wiring of LEDs, diodes and low-voltage signal lines. Avoid exposure to high voltages, excessive heat or mechanical strain; if longer runs or higher current are required, choose an appropriately rated cable.
