DELTA Power Distribution Terminal Block KG-1, 1-Pole, 32A, 250V, White

The DELTA Power Distribution Terminal Block KG-1 is a high-quality single-pole terminal block designed for reliable power distribution in electrical installations. With a rated current of 32A and voltage of 250V AC, it is suitable for a wide range of applications. The terminal block features one input and three output terminals, allowing efficient distribution of power to multiple devices. Its compact design and screw clamp terminals ensure secure and easy wiring.

Advantages

This terminal block offers several advantages: it is made from durable polyamide (PA) housing with brass conductors, ensuring long-lasting performance and excellent conductivity. The surface mount design with screw fixing allows for simple installation on walls or panels. The IP20 rating provides protection against solid objects larger than 12.5 mm, making it safe for indoor use. Additionally, the white color blends well with most environments.

Suitable for

• Power distribution in control cabinets
• Electrical installations in residential and commercial buildings
• Connecting and branching power cables
• DIY and professional electrical projects

Key specifications

• Type: Power Distribution Terminal Block
• Number of Poles: 1 (Single-pole)
• Input Terminals: 1
• Output Terminals: 3
• Rated Voltage: 250V AC
• Rated Current: 32A
• Input Wire Cross-section: 1.5 - 6 mm² (flexible/rigid)
• Output Wire Cross-section: 1.5 - 2.5 mm² (flexible/rigid)
• Mounting Type: Surface Mount (Screw Fixing)
• Terminal Type: Screw Clamp
• Body Material: Polyamide (PA)
• Conductor Material: Brass
• Color: White
• IP Rating: IP20
• Operating Temperature: -25°C to +70°C
• Standards: PN-EN 60998-1

Recommendations

For optimal performance, ensure that the wire cross-sections are within the specified ranges and that the screw terminals are tightened to the recommended torque. This terminal block is ideal for indoor use only and should be installed by a qualified electrician.
