DELTA BD-B116 Universal Wall Mount Bracket for Dome and Bullet Security Cameras, Aluminum Alloy, White, 2 kg Load Capacity, Indoor/Outdoor

When standard camera mounts force you to compromise on placement, the DELTA BD-B116 offers a refreshingly straightforward solution. This L-shaped wall bracket is crafted from powder-coated aluminum alloy, giving you a corrosion-resistant platform that works just as well outdoors as it does inside. It is universally compatible with most dome and bullet security cameras, so you can position your camera exactly where it needs to be without hunting for a model-specific bracket.

Highlights

• Universal fit for most dome and bullet security cameras
• Durable aluminum alloy construction with white powder-coated finish
• Supports cameras up to 2 kg
• Integrated cable pass-through keeps wiring tidy
• Suitable for indoor and outdoor use, with corrosion resistance
• Includes mounting hardware (screws and wall plugs)

In daily use

The BD-B116's fixed L-shaped design gives you a stable, low-profile mounting point that keeps the camera close to the wall while still allowing a clear field of view. The integrated cable channel routes the camera's cable through the bracket, reducing exposed wiring and protecting it from the elements. Installation is simple: use the included screws and wall plugs to secure the 70 x 40 mm base to a wall or ceiling, then attach your camera to the 50 x 50 mm mounting plate. The 6 mm mounting holes are pre-drilled for convenience. With an operating temperature range of -20°C to 50°C and humidity tolerance up to 95% RH (non-condensing), this bracket handles harsh environments without flinching.

Full specifications

• Mount type: Wall mount
• Material: Aluminum alloy
• Colour: White
• Compatibility: Universal for most dome and bullet security cameras
• Load capacity: Up to 2 kg
• Adjustability: Fixed position
• Installation method: Screw-fixed
• Application environment: Indoor & outdoor
• Cable management: Integrated cable pass-through
• Mounting base dimensions: 70 x 40 mm
• Arm length: 110 mm
• Camera mounting plate dimensions: Approx. 50 x 50 mm
• Mounting hole diameter: 6 mm
• Finish: Powder coated
• Corrosion resistance: Yes
• Operating temperature: -20°C to 50°C
• Operating humidity: 0-95% RH (non-condensing)
• Mounting hardware: Included (screws and wall plugs)
• Design: L-shaped bracket

Final note

For a dependable, no-fuss mounting solution that works with a wide range of security cameras, the DELTA BD-B116 delivers the strength and weather resistance you need, indoors or out.
