Conceptronic 4-Port DB9 RS232 Serial PCIe Card, PCIe, RS-232, PCIe 2.0, RS-232, Black, China

Conceptronic 4-Port DB9 RS232 Serial PCIe Card, PCIe, RS-232, PCIe 2.0, RS-232, Black, China
Conceptronic 4-Port DB9 RS232 Serial PCIe Card, PCIe, RS-232, PCIe 2.0, RS-232, Black, China
Conceptronic 4-Port DB9 RS232 Serial PCIe Card, PCIe, RS-232, PCIe 2.0, RS-232, Black, China
Conceptronic 4-Port DB9 RS232 Serial PCIe Card, PCIe, RS-232, PCIe 2.0, RS-232, Black, China
Conceptronic 4-Port DB9 RS232 Serial PCIe Card, PCIe, RS-232, PCIe 2.0, RS-232, Black, China
Conceptronic 4-Port DB9 RS232 Serial PCIe Card, PCIe, RS-232, PCIe 2.0, RS-232, Black, China
R1,084
The 4-Port DB9 RS232 Serial PCIe Card features four serial ports, providing an easy expansion for additional devices. The serial ports support the RS-232 protocol with a transmission speed of up to 115200bps and also support hardware and software flow control. Conceptronic 4-Port DB9 RS232 Serial P... Read More
Stock 80 Code 1504217 Brand CONCEPTRONIC Model EMRICK12B Warranty 2 Years

Shipping & Returns

Estimated delivery Thursday, October 15
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
The 4-Port DB9 RS232 Serial PCIe Card features four serial ports, providing an easy expansion for additional devices. The serial ports support the RS-232 protocol with a transmission speed of up to 115200bps and also support hardware and software flow control.

Conceptronic 4-Port DB9 RS232 Serial PCIe Card. Host interface: PCIe, Output interface: RS-232, Expansion card standard: PCIe 2.0. Product colour: Black, Country of origin: China. FIFO (First In, First Out): 256 B. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10.... Width: 85 mm, Depth: 69 mm, Height: 3 mm

Key Highlights
  • Expands your system's connectivity with the addition of 4 RS232 (DB9) serial ports
  • Compliant with PCI Express 2.0 Gen 1
  • On chip 256-byte depth FIFO in transmit, receive path of each port
  • Supports Slow IrDA mode (up to 115200bps) on all serial ports
  • Internal
  • Host interface: PCIe
  • Output interface: RS-232
  • Black
Specifications
Compliance certificates
CE, RoHS
Country of origin
China
Depth
69 mm
Drivers included
Yes
Expansion card standard
PCIe 2.0
FIFO (First In, First Out)
256 B
Harmonized System (HS) code
8471800000
Height
3 mm
Host interface
PCIe
Internal
Yes
Linux operating systems supported
Yes
Master (outer) case gross weight
10 kg
Master (outer) case height
350 mm
Master (outer) case length
380 mm
Master (outer) case width
490 mm
Master (outer) cases per pallet
30 pc(s)
Operating relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
-10 - 55 °C
Output interface
RS-232
Package depth
140 mm
Package height
75 mm
Package type
Box
Package width
172 mm
Pallet gross height
163 cm
Pallet gross length
80 cm
Pallet gross width
120 cm
Product colour
Black
Products per master (outer) case
25 pc(s)
Quick installation guide
Yes
Serial interface type
RS-232
Serial ports quantity
4
Storage temperature (T-T)
-40 - 70 °C
Sustainability compliance
Yes
Weight
250 g
Width
85 mm
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64

Manual

Open Manual

Leaflet

Open Leaflet

Document

Open Document
