Coaxial Load Televes 519425 Type F Female 5-1220 MHz

Coaxial Load Televes 519425 Type F Female 5–1220 MHz is a compact 2-way tap designed for CATV and DOCSIS 3.1 compatible coaxial installations. The unit uses Type F connectors and offers a frequency range from 5 to 1220 MHz. Its miniaturized electronic components deliver efficient electrical performance, while a Zamak metal chassis provides effective electromagnetic shielding. The product is intended for indoor installation and can be mounted on a wall, rack plate or standard DIN rail; it is supplied in 10-unit boxes.

Advantages

The Televes 519425 provides stable signal termination across a wide frequency band (5–1220 MHz) and is compatible with DOCSIS 3.1 systems. Its small dimensions (74 × 18 × 54 mm) make it suitable for space-constrained installations. The Zamak chassis improves shielding against interference, and the use of standardized Type F connectors ensures broad compatibility with CATV equipment.

Suitable for

• CATV distribution networks
• DOCSIS 3.1 cable system terminations
• Indoor wall, rack plate or DIN rail installations
• Termination of coaxial lines to reduce reflections

Key specifications

• Model: Televes 519425
• Connector type: F female (Type F)
• Frequency range: 5–1220 MHz
• Compatibility: DOCSIS 3.1
• Dimensions (W × D × H): 74 × 18 × 54 mm
• Chassis material: Zamak (metal)
• Packaging: 10 units per box
• EAN: 8424450287972

How to use

Install the Televes 519425 indoors and mount it on a wall, rack plate or standard DIN rail according to the installation layout. Connect the coaxial cable to the Type F female connector, ensuring a secure threaded connection. Use the device to terminate coaxial lines or to create a 2-way tap in the CATV distribution, taking care to follow system grounding and cable management practices to maintain signal integrity.

Recommendations

For best performance, use the Televes 519425 within the specified 5–1220 MHz range and in DOCSIS 3.1 compliant systems. Ensure proper grounding and avoid exposure to outdoor conditions; store and install the unit indoors. Verify connector tightness after installation and use compatible Type F cables and components.
