Coaxial Connector ShiverPeaks BS85210

The ShiverPeaks BS85210 coaxial connector is a single-piece, 90° angled adapter with F-type female connectors on both ends designed for reliable RF signal transmission. Its compact right-angle form factor facilitates connections in confined spaces where straight cables would be impractical. The connector is suitable for home installations, AV systems and cable TV or satellite lines where an angled interface reduces cable strain and improves routing convenience.

Advantages

This coaxial connector provides a stable electrical connection with consistent impedance for minimal signal loss. The 90° orientation reduces bending stress on coaxial cables and helps maintain neat cable management behind equipment, wall plates or inside cabinets. Constructed as a single-piece unit, the adapter offers simple plug-and-play installation without additional tools and maintains mechanical stability in repeated insertions.

Suitable for

• Home theater and AV equipment connections
• Cable TV and digital television leads
• Satellite receiver and set-top box installations
• Tight or recessed installation points where straight connectors are impractical

Key specifications

• Connector type: F-type female to F-type female adapter
• Orientation: 90° right-angle
• Construction: single-piece design
• Application: RF signal and coaxial cable connections for TV, satellite and AV systems
• Compatibility: standard coaxial cables with F-type terminations

How to use

Align the F-type connectors with the corresponding coaxial cable ends or device ports and screw the adapter on by hand until snug. Ensure the cable outer conductor and centre conductor are properly terminated on the mating connectors before attaching the adapter. Avoid over-tightening to prevent damage to the connector body or equipment ports. Position the connector so the 90° bend relieves cable stress and achieves the desired routing path.

Recommendations

For best performance, use this right-angle coaxial connector with properly prepared F-type terminated coax cables and avoid excessive bending near the connection point. Inspect connections periodically for corrosion or looseness, especially in outdoor or humid environments; replace if signal degradation is observed.
