Coaxial Connector F-type ShiverPeaks BS15-301714

The ShiverPeaks BS15-301714 F-type coaxial connectors are a set of four F-to-F inline couplers designed to join or extend coaxial cables without altering signal path polarity. Each connector provides a straightforward, threaded connection on both ends to ensure compatibility with standard F-type male cable and device fittings. These compact couplers are intended for use in cable television, satellite, and other RF distribution systems where a stable mechanical and electrical joint is required.

Advantages

These F-type coaxial connectors provide a simple and reliable solution for extending coaxial runs or connecting cables in tight installations. The threaded F-type interfaces deliver consistent impedance matching and minimize insertion loss when used with properly prepared coaxial cables. Their compact metal housings offer mechanical durability and good shielding against external interference, supporting stable signal transmission for TV and satellite applications.

Suitable for

• Joining two coaxial cables of the same F-type termination
• Extending runs for cable TV and satellite installations
• Temporary or permanent inline connections in home and small commercial AV systems
• Connecting set-top boxes, modems, splitters, and wall outlets with F-type fittings

Key specifications

• Connector type: F-type female to F-type female inline coupler
• Pack quantity: 4 pieces
• Suitable cable: standard coaxial cables with F-type male fittings
• Material: metal housing with threaded ferrule (provides shielding and mechanical strength)
• Impedance: intended for 75 ohm RF systems
• Application frequency: suitable for VHF/UHF, cable TV and satellite frequency ranges

How to use

Prepare both coaxial cable ends with properly terminated F-type male connectors. Align the male connector threads with the coupler and screw until hand-tight; avoid excessive torque to prevent damage to threads or cable center conductor. For best electrical performance, ensure the cable shields and center conductors are properly seated in their respective F-type terminations before coupling. Test signal continuity and quality after installation and, if necessary, secure connections with appropriate strain relief or cable clamps to prevent mechanical stress.

Recommendations

Use these F-type couplers in dry, indoor environments or in weather-protected outdoor enclosures. For outdoor or exposed installations, consider using weatherproof boots or sealing tape over the threaded connections to prevent moisture ingress. When high-frequency or critical-signal runs are required, minimize the number of inline couplers and use high-quality, matched coaxial cabling to reduce potential signal loss.
