Coaxial Connector F-type Axing QEW 4-20

The Axing QEW 4-20 is a compact F-type coaxial connector designed for reliable signal transmission in antenna, satellite and cable TV installations. Featuring two F-type ports, the connector enables straightforward inline linking or adapter-style connections between coaxial cables and equipment. Its durable metal construction and compact form factor make it suitable for confined installation spaces while maintaining consistent electrical contact and signal integrity.

Advantages

The connector provides stable mechanical and electrical coupling for coaxial cables, reducing signal loss at connection points. Its dual F-type interfaces allow easy daisy-chaining or transition between different cable runs without the need for additional tools. The robust housing resists deformation during installation and supports repeated mating cycles, ensuring long-term usability in both residential and professional setups.

Suitable for

Key specifications

How to use

Prepare the coaxial cable ends according to standard F-type termination procedures and ensure connectors are clean and free of debris. Align the F-type connectors and hand-tighten until secure; use a suitable wrench only if necessary to avoid over-tightening. Verify continuity and signal quality after installation using an appropriate signal meter or by checking the connected device. For best results, make sure cable shielding and center conductor are properly engaged in the mating connector.

Recommendations

Use the connector in dry, protected environments or within weatherproof enclosures when installed outdoors. Avoid excessive bending or strain on connected cables and periodically inspect connections for corrosion or looseness to maintain optimal signal performance.
